| BRAND | Bauer |
| Product | P/N 188P3185 (Type BG06-31/D06LA4-TOF/UL-SP) |
| Description | Helical-geared motor |
| Internal code | YUS4004679 |
| Weight | 9.5 |
| Technical specification | Material number 30410781 BCAS item number 188P3185 Description BG06-31/D06LA4-TOF/UL-SP Item number: 188P3185 Helical-geared motor BG06-31/D06LA4-TOF/UL-SP Motor power: 0.25 kW Output shaft speed: 42.0 rpm Mount: B5 Terminal box position: II/D Corrosion protection: Standard Painting: unpainted Dimensional drawing: BG06 Catalogue: DG 07 Net weight per unit: approximately 9.5 kg Add.-/Special design: Output plate additional stamped with: Customer ID no. 207398 Total thickness of coating 0 µm Suitable for ambient temperatures from -10 to 60°C. Without terminal board (cable with end connector BAU2554194 connected to motor wires) Complete design in accordance with ZN.TEM151203-A3-1. Special cable motor in accordance with ZN.BAU2543478. MWN0543 Ölflex Quattro 7x0.75 mm² long with phoenix plug with hexagonal nut M20 BAU2532182 and O-ring BAU2525356 Special cable glands in accordance with ZN.BAU2580705. M20x1.5 MS Skintop Suitable for operation on static converter In the frequency range: 5 - 50 - 87 - 110 Hz Voltage: 30 - 133 - 230 - 230 V D Power: 0.016 - 0.25 - 0.445 - 0.51 kW Synchronous speed: 4.6 - 46.5 - 81 - 102 rpm Load moment: 34.0 - 56 - 56 - 50 Nm Load current approximately: 2.85 A Service factor: 0.8 Gear design: Type: BG06 2-staged helical gear Design Code 31 with standard flange on side front (d: 120 mm) Solid output shaft on gear side front (d: 17 mm) Total gear reduction i: 32.22 Add.-/Special design: Special gear housing in accordance with ZN.BG06-03-A2-AL-K3. M8 thread material. -No.: BAU2543443 Design of the motor: Type: three-phase squirrel cage motor D06LA4-TOF Rated speed: 1350 rpm Voltage: 133 V Connection: D Frequency: 50 Hz Rated current: 2.65 A Power factor cos phi: 0.69 Temperature class: F IP protocol type according to EN 60529: IP 65 IC cool. type EN 60034-6: IC 411 Terminal box: KAG2 Designed according to DIN VDE 0530-1/EN 60034-1 Add.-/Special design: With built-in thermostats “opening” for release Correlate to Insulation Class F via Supplemental Connection Diagram Z010.1030-13. Design of the motor acc. to UL file E220923 Fan made of special plastic B3 G5 ULTRAMID. Turn left when U-V-W is connected to L1-L2-L3 Terminal box design with terminal block State. Item no. 85015100 Country of origin Slovakia Operating manual DE Net weight 9,500 KG |
Where can I buy P/N 188P3185 (Type BG06-31/D06LA4-TOF/UL-SP) by Bauer in Japan?
You can purchase P/N 188P3185 (Type BG06-31/D06LA4-TOF/UL-SP) by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the P/N 188P3185 (Type BG06-31/D06LA4-TOF/UL-SP)?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Bauer in Japan?
While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.
How can I access P/N 188P3185 (Type BG06-31/D06LA4-TOF/UL-SP) catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for P/N 188P3185 (Type BG06-31/D06LA4-TOF/UL-SP) on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for P/N 188P3185 (Type BG06-31/D06LA4-TOF/UL-SP)?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
