Prices BS02-71V/DU05LA4-TOF/SP Bauer Japan

BRAND	Bauer
Product	BS02-71V/DU05LA4-TOF/SP
Description	BS WORM-GEARED MOTOR
Internal code	YUS3998169
Weight	7.4
Custom code	85015100
Technical specification	Material number 30618889 Article number 189D0124 Motor power: 0.12 kW Speed of the AW: 100 r/min Torque: 8.9 Nm Operating factor fB: 2.8 Line-up: H1 Terminal box location: II/A Corrosion protection: standard Painting: RAL 7031 Measurement image: BS02 Catalogue: DG 07 Net weight per piece: approx. 7.4 kg Additional/special versions: Rating plate additionally stamped with: Customer ID No. 24131466 Transmission design: Type: BS02 1-stage worm gear Model number 71V C-flange with threaded holes on the front side Pivot shaft on transmission side V (d: 14 mm) Total reduction i: 13.50 Additional/special versions: Lubricant type: PGLP 220 Motor design: Type: DU05LA4-TOF three-phase squirrel cage motor Rated speed: 1350 r/min Voltage: 230 V Stand circuit: D frequency: 50 Hz Rated current: 0.73 A Power factor cos phi: 0.73 Warmth class: F IP protection class according to EN 60529: IP 65 IC cooling type according to EN 60034-6: IC 410 Terminal box: KAG2 Design in accordance with DIN VDE 0530-1/EN 60034-1 Additional/special versions: With built-in thermostat “opener” for shut-off in accordance with insulation class F according to additional connection diagram ZK010.1030-03. With screwed-on motor base

Bauer - BS02-71V/DU05LA4-TOF/SP referenced BS WORM-GEARED MOTOR product produced by high technology.
BS02-71V/DU05LA4-TOF/SP became irreplaceable of foundations. It distinguishes with price and quality among the similar products. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Make an offer to us for BS02-71V/DU05LA4-TOF/SP please contact us.

Where can I buy BS02-71V/DU05LA4-TOF/SP by Bauer in Japan?

You can purchase BS02-71V/DU05LA4-TOF/SP by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the BS02-71V/DU05LA4-TOF/SP?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Bauer in Japan?

While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.

How can I access BS02-71V/DU05LA4-TOF/SP catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for BS02-71V/DU05LA4-TOF/SP on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for BS02-71V/DU05LA4-TOF/SP?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
