Prices  AT1-182040R / T1-60G-GKGM  Steimel  Japan

BRAND Steimel
Product AT1-182040R / T1-60G-GKGM
Internal code YUS4625171
Weight 80
Custom code 84136039
Technical specification ATEX aggregate PTFE, GD, EC, AW, G3/4, M37GN/10, M.Ybx469, MR3Z02.0-386 rpm Gear pumps - aggregate: T 1 - 60/G - GKGM according to Directive 2014/34/EU (ATEX) Item number: AT1-182040R Dimension sheet: DPA001-182040R Spare parts list (pump only): DET001-A031R Operating instructions: DBA-ZP02 + DBA-ZP-ATEX-01 Suction and discharge connection: G ¾ Material finish: Housing parts: EN-GJL-250 (EN-JL 1040) Drive and counter pinion: 16 MnCrs 5, hardened straight-toothed Shaft seal: mechanical seal M 37 GN/10+K+R Q12Q1KGG1 Elastomers of the mechanical seal: Kalrez temperature monitoring on the mechanical seals: 1 PTC thermistor (ATEX), BTW062 wired to Ex terminal box, NAT: 100 °C iBexu 14 ATEX 1291X Display device: on-site Bearing Bushings: Bronze AW increased bearing clearance: without Case seal: Loctite other elastomers: PTFE Extraction hole: without Pumped medium: paints and varnishes solvent-based, pigment-containing, max. 100 μm grain size Concentration: 10 - 70% Viscosity: 1,000 - 2,000 mm2/s Temperature: max. 70 degrees C rinsing with solvent (viscosity 30 - 1000 mm2/s) approx. 10% of the passage of time Delivery data: Q: 0 - 300 L/h p: 0 - 3 bar (pump must suck) n: 0 - 250 rpm direction of rotation: right Test run: yes, with HLPD 46 Pre-cleaning: rinse with mineral spirits Base plate: EGP913045-21BB05 base plate with vibration dampers for free installation on indoor floors article - no.: ILW040x30x55und 4x Ø14 Dispatch fixing holes Coupling: BKUP078-1020-001 Clutch protection: BKS918100080AC01 (sheet brass tread resistant) Pad: EUL—032100BB01 plaromaster ball roller gearbox with intermediate gear and motor Make: Planetroll with ATEX - attesting Type: 0.37D2 (Ex) MR3Z02 - 3, 109 - 1 Product no.: LGM037MR3—001 engine data Power P: 0.37 kW output speed n: 0 - 386 rpm Rated speed - motor n: 2825 rpm Voltage U: 230/400 volts Frequency f: 50 Hz Degree of protection: IP 55 Insulation class: F explosion-proof: Ex e II T 3 Design: B 3 Control element:type HVK, analog display, coarse scale 0-12, fine scale 0-100, viewing window at the top ATEX nameplate: Enter control range Paint: RAL 5009 (HDE) Silicone-free pump! The pump was tested with mineral oil and must be flushed on site before commissioning! Sign: EAY924-PL02 Identification plate: ETY924-D-E—PE03 ATEX marking: II 2G Ex h IIB T3 Gb Please observe the provisions of Directive 2014/34/EU (ATEX) regarding the use of our pumps in hazardous areas. Prerequisite for operation according to: Ex zone 1 (gas), temperature class T 3, Ambient temperature -20 to 40°C Explosion group IIB. Attention: Before starting the pump, the temperature monitoring can be connected functionally!

Steimel - AT1-182040R / T1-60G-GKGM referenced product produced by high technology.
AT1-182040R / T1-60G-GKGM became irreplaceable of foundations. AT1-182040R / T1-60G-GKGM referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. AT1-182040R / T1-60G-GKGM referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy AT1-182040R / T1-60G-GKGM by Steimel in Japan?

You can purchase AT1-182040R / T1-60G-GKGM by Steimel from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the AT1-182040R / T1-60G-GKGM?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Steimel in Japan?

While we are not the official distributor or seller of Steimel in Japan, we source our products from reliable channels and offer you original Steimel equipment at competitive prices.

How can I access AT1-182040R / T1-60G-GKGM catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for AT1-182040R / T1-60G-GKGM on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for AT1-182040R / T1-60G-GKGM?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
