Prices SF 2/20 RD - VLFM Steimel Japan

BRAND	Steimel
Product	SF 2/20 RD - VLFM
Description	pump
Internal code	YUS4282734
Weight	28.55
Custom code	84136039
Technical specification	ASF2-20RD-171081R A-SF2/20RD-VLFM, pump unit, 2-20 bar 1.5 kW, 1500, 230/400V, IE3, 50Hz, IP55, B5, electr. NEMA Product no.: ASF2-20RD-171081R Dimension sheet: DPA052D-090LFM-R33 Spare parts list: DET052020RD—165R Suction and pressure connection: G 1/SAE 1 Housing Parts: EN-GJL-250 (GG-25) Sprocket shafts, noise.: 16mnCRS5, Egh., inclined. Storage: Multilayer MD Shaft sealing: radial shaft seal Elastomers: FKM Pumped medium: lubricating oil Viscosity: 50 - 5000 cSt Temperature: 10 - 60°C Flow rate: approx. 28.4/34 l/min. Pressure: 5 bar Speed: 1410/1692 rpm Pressure Relief Valve Opening pressure: 8 bar Adjustment range: 2-20 bar Direction of rotation: right Trial: yes, with HLPD 46 Clutch: BKUA040-1424-301 Pump carrier with foot: BLF052200110LA21 3-phase motor: LDM090-04-217 (birch dent) Engine data: Power 1/2:1.5/1.8 kW Speed 1/2:1500/1800 rpm. Voltage/frequency 1:230/400 volts at 50Hz Voltage/frequency 2:266/460 volts at 60Hz Efficiency class: IE3 Degree of protection: IP 55 Insulation class: F Special feature: electrical according to NEMA Design: B 5 Aggregation coat: primed HDO058 - green Identification plate: ETY924-D-E—PE02

Steimel - SF 2/20 RD - VLFM referenced pump product produced by high technology.
You can ask all the codes and references except SF 2/20 RD - VLFM too. Our company supply SF 2/20 RD - VLFM referenced product fastest and securest on your request. You can find the most competitive prices about endustriel accessories in our company. We present you the most competative price and delivery time on SF 2/20 RD - VLFM referenced product.

Where can I buy SF 2/20 RD - VLFM by Steimel in Japan?

You can purchase SF 2/20 RD - VLFM by Steimel from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the SF 2/20 RD - VLFM?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Steimel in Japan?

While we are not the official distributor or seller of Steimel in Japan, we source our products from reliable channels and offer you original Steimel equipment at competitive prices.

How can I access SF 2/20 RD - VLFM catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for SF 2/20 RD - VLFM on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for SF 2/20 RD - VLFM?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
