Prices ASF6-180RD151529R Steimel Japan

BRAND	Steimel
Product	ASF6-180RD151529R
Description	pumping unit
Internal code	YUS1224511
Weight	130
Custom code	84136039
Technical specification	A-SF6/180RD-VLFM, pump unit, 2-16 bar 11.0 kW, 1500, 400/690 V, 50 Hz, IP55, F, B5, IE3 Length 970.00 mm Width 360.00 mm Height 470.00 mm Gear pump unit: SF 6/180 RD - VLFM Item number: ASF6-180RD151529R Dimension sheet: DPA056D-160LFM-R32 Spare part list: DET056180RD--165R Suction and pressure connection: SAE 2 ½ Housing parts: EN-GJL-250 (GG-25) Waves: 16MnCrS5, egh. gears, noise-optimized: EN-GJS-400-15 (GGG-40), ionitrized, helically toothed Shaft seal: radial shaft seal Elastomers: FKM Pumping medium: lubricating oil Viscosity: 50-5000 cSt Temperature: 10-60°C Flow rate: approx. 256/307 l/min. Pressure: 5 bar Speed: 1450/1740 rpm. pressure relief valve Opening pressure: 8 bar Adjustment range: 2-16 bar Direction of rotation: right Test run: yes, with HLPD 46 Coupling: BKUA095-2442-301 Pump carrier with foot: BLF056350188LA21 Three-phase motor: LDM160-04-027 (Birkenbeul) Motor data: Output 1/2:11/12.6 kW Speed 1/2:1500/1800 rpm Voltage/ frequency 1:400/690 volts at 50 Hz Voltage/ frequency 2:460 volts - triangle at 60 Hz Efficiency class: IE3 with additional sign (without IE 2) for Voltage/ frequency: 380-420/660-720 V at 50/60 Hz 440-480 V - triangle at 60 Hz Protection class: IP 55 Insulation class: F Design: B 5 Aggregate paint: primed Type plate: ETY924-D/E--PE02

Steimel - ASF6-180RD151529R referenced pumping unit product produced by high technology.
ASF6-180RD151529R became irreplaceable of foundations. Our company supply ASF6-180RD151529R referenced product fastest and securest on your request. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for ASF6-180RD151529R Steimel . Make an offer to us for ASF6-180RD151529R please contact us.

Where can I buy ASF6-180RD151529R by Steimel in Japan?

You can purchase ASF6-180RD151529R by Steimel from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the ASF6-180RD151529R?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Steimel in Japan?

While we are not the official distributor or seller of Steimel in Japan, we source our products from reliable channels and offer you original Steimel equipment at competitive prices.

How can I access ASF6-180RD151529R catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for ASF6-180RD151529R on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for ASF6-180RD151529R?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
