Prices SF 3/40 G - VLFM Steimel Japan

BRAND	Steimel
Product	SF 3/40 G - VLFM
Description	gear pump unit
Internal code	YUS4485885
Weight	8
Custom code	84136039
Technical specification	A-SF3/40G-VLFM 0.55 kW, 900, 600V, 60Hz, IP55, ship version, IE2, LR acceptance Product no.: ASF3-40G--200160R Dimension sheet: DPA053-200160R Spare part list: DET053040G---151R Suction and pressure connection/ : SAE 1 ½ (DN 40) material design Housing parts: EN-GJL-250 (GG 25) Sprocket shafts: 16 Mn Cr S 5, insert hardened diagonally toothed, toothed flanks Shaft seal: mechanical seal/ M2/20+V+R Elastomers: FKM Storage: bronze AW/bronze AW Extraction medium: diesel oil/diesel oil Viscosity: approx. 5 cSt Temperature: 10-60°C Delivery data Q: 2 m³/h p: 2.5 bar n: 810 rpm Direction of rotation: right/cw pump carrier with foot : BLF053200118LA21 Coupling: BKUA040-1924-301 with three-phase standard motor: IEC 90 Article number: LDM090-08-015 in ship version in accordance with LROs but without acceptance/ with factory test certificate 3.1 in accordance with EN10204 Construction situation: cable entry in the terminal box rotated 180° to the print side (according to dimensional drawing)/ Power P: 0.55 kW Speed n: 900 rpm Voltage: 600 volts (no multi-range voltage) Frequencies: 60 Hz efficiency class class: not subject to EU regulation 640/2009 and IEC 60034-30 640/2009 and IEC 60034-30 insulation class Class: F Protection class: IP 55 Design: B 5 Suction line: BRL053-NW40-B-01 with flange NW 40, DIN 2633 Pressure line: BDL053-DBV--B-04 (with weld-on screw connection for pipe Ø 28 at the end of the line) with integrated Pressure relief valve/ : G 1 with straight screw-in screw in the bypass connection Article no./Art no: BDV-G1----15-105 Sectional drawing: DSZ-DV-05 Spare parts list: DET-DV-G1----105 Threaded connections: G 1 materials: Housing parts: EN-GJL-250 (GG-25) Valve cone: 16MnCrS5 Elastomers: FKM Operated by: disc spring/ Pressure range (adjustable): 1-15 bar opening pressure Pressure: 3 bar sealed with sealing wax Type plate-DBV: ETY924-D/E-PE02 Aggregate type plate : ETY924-D/E-PE02 Coating: RAL 9010 (HDE9010, pure white)

Steimel - SF 3/40 G - VLFM referenced gear pump unit product produced by high technology.
SF 3/40 G - VLFM became irreplaceable of foundations. SF 3/40 G - VLFM referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Contact us if you are looking for alternative price of SF 3/40 G - VLFM .

Where can I buy SF 3/40 G - VLFM by Steimel in Japan?

You can purchase SF 3/40 G - VLFM by Steimel from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the SF 3/40 G - VLFM?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Steimel in Japan?

While we are not the official distributor or seller of Steimel in Japan, we source our products from reliable channels and offer you original Steimel equipment at competitive prices.

How can I access SF 3/40 G - VLFM catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for SF 3/40 G - VLFM on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for SF 3/40 G - VLFM?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
