Prices ASF2-8RD--170063R Steimel Japan

BRAND	Steimel
Product	ASF2-8RD--170063R
Internal code	YUS4748396
Weight	25
Custom code	84136039
Technical specification	A-SF2/8RD-LFM, pump unit, 2-20 bar 0.75 kW, 1500, 230/400 V, 50 Hz, IP55, F, B5, IE3 Gear pump unit: SF 2/8 RD - LFM Product no.: ASF2-8RD--170063R Dimension sheet: DPA052D-170063R Spare part list: DET052008RD-165R Suction and pressure connection: G 1/SAE 1 Housing parts: EN-GJL-250 (GG-25) Sprocket shafts, noiseless: 16MnCrS5, egh., helical Storage: multi-layer Shaft sealing: radial shaft seal Elastomers: FKM Pumping medium: lubricating oil Viscosity: 50-5000 cSt Temperature: 10-60°C Flow rate: 10.9/13 l/min. Pressure: 5 bar Speed: 1400/1680 rpm. pressure relief valve Adjustment range: 2-20 bar Opening pressure: 8 bar Direction of rotation: right Test run: yes, with HLPD 46 Coupling: BKUA040-1419-301 Pump carrier with foot IJN200: BLF052200101LA11 Three-phase motor: LDM080-04-904 Motor data: Output 1/2:0.75/0.8 kW Speed 1/2:1500/1800 rpm Voltage 1:230/400 volts at 50 Hz Voltage 2:265/460 volts at 60 Hz Efficiency class: IE3 Protection class: IP 55 Insulation class: F Design: B 5 Aggregate paint: primed Identification plate: ETY924-D-E--PE02

Steimel - ASF2-8RD--170063R referenced product produced by high technology.
ASF2-8RD--170063R became irreplaceable of foundations. All of the listed products are with guaranteed origin and high quality. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for ASF2-8RD--170063R Steimel . We present you the most competative price and delivery time on ASF2-8RD--170063R referenced product.

Where can I buy ASF2-8RD--170063R by Steimel in Japan?

You can purchase ASF2-8RD--170063R by Steimel from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the ASF2-8RD--170063R?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Steimel in Japan?

While we are not the official distributor or seller of Steimel in Japan, we source our products from reliable channels and offer you original Steimel equipment at competitive prices.

How can I access ASF2-8RD--170063R catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for ASF2-8RD--170063R on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for ASF2-8RD--170063R?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
