| BRAND | Fimet |
| Product | X3GAA3THN11.0BDX64 |
| Description | reducer motor |
| Internal code | YUS4967645 |
| Technical specification | FIMET COAXIAL GEAR MOTOR TYPE RK7E B3 AC MOTOR AAO 180 L 8 460/265V 60HZ B5 REDUCTION RATIO 1/11.0 COMPLETE WITH IDEACOD GHU9 20 8 9 R/700 ENCODER WITH HEADS CONNECTED IN TERMINAL BLOCK PROTECTION FOR OPERATION IN HUMID AND TROPICAL ENVIRONMENTS; FINAL PAINTING COLOR BLUE RAL 5015; EXTERNAL GROUND SOCKET; BRASS FITTINGS; SEPARATE BRAKE SUPPLY 460Vac (**); BRAKING TORQUE REDUCED BY 50%; DOUBLE IMPREGNATION; AMBIENT TEMPERATURE 45°C; VENTILATION ASSISTED BY 3MAA63A6; BRAKE HEADS (**) IN A SEPARATE BASE IN A BOX ADDED TO THE RIGHT SIDE OF THE ENGINE; 13KW 79.1 RPM - SUITABLE WINDING |
