| BRAND | AEG |
| Product | Protect 8.33 |
| Description | UPS |
| Internal code | YUS4717715 |
| Weight | 712.5 |
| Technical specification | a) Rectifier:
Supply voltage: 400 V 15%/3 Ph./PE
(adjustable to 3x380 V or 3x 415 V)
Power consumption at rated load: 98 A at 400 V
Power consumption at rated load
and battery charge: 123 A at 400 V
Network effects: 6-pulse+ filter
Frequency: 50 Hz 10% or 60 Hz 10%
DC output voltage: 384 V 20%
b) Inverter:
Nominal output: 60 kVA (at cos = 0.8 ind.)
AC output voltage: 400 V/3 Ph./N/PE
Variance, static: 1%
Deviation, dynamic: < 2% (in case of load surge 0 - 100% - 0 without network assistance)
Frequency: 50 Hz, optional 60 Hz
Power factor range: 0 ind. - 1 - 0 kap.
Output phase current: 87 A at 400 V
Voltage curve shape: sinusoidal
Distortion factor: < 3% in total DC voltage,
Load and power factor range
Non-linear load: up to 100% of the rated UPS capacity
Short circuit current L-N 500 ms 3.22 x Inenn
Short circuit current 3-phase 500 ms 1.81 x Innn
Crest factor: 3, distortion factor where < 3%
Overload behavior: 150% for 1 min., 125% for 10 min.
c) General data:
Supply voltage (EUE): 400 V 10% (adjustable)/3 Ph./N/PE
overall efficiency
100% load (PF=0.8): 91.9 ± 2%
Radio suppression degree: “A” in accordance with EN 62040-2
Immunity: according to EN 61006-4
Cooling type: reinforced air self-cooling with built-in
redundant fans
Operating mode: continuous operation
Painting: RAL 7035 (powder coating)
Protection class: IP20
Dimensions (WxHxD): 750 mm x 1800 mm x 860 mm |
