| BRAND | Airpel |
| Product | DELTA-OW/WB |
| Description | Sieve basket filter |
| Internal code | YUS4218818 |
| Weight | 49.35 |
| Technical specification | 00360024 as double filter, 2" Housing material: cast iron EN-JL 1030 Entry and exit: R 2" female thread Inline design, i.e. entrance and exit at a height opposite max. allowable pressure PS: 17 bar Operating pressure: unknown permissible max. temperature TS: 50°C Operating temperature: unknown Volume V: 9 litres Drain plug: 1/2" BSP, Material Brass Sealing material: FPM Socket: Bronze BS1400 LG2C Reversible taps: Bronze BS1400 LG2C Sealing/storage of the reversible taps: metallic Internal machine parts: Stainless steel 1.4305 Weight empty: 49 kg Number of mesh baskets: 1 piece (per filter chamber) Conformity assessment according to Pressure Equipment Directive 2014/68/EU Classification referred to in Article 4 (3), 'good engineering practice' Fluid group 2, liquid (steam superpressure pD <= 0.5 bar) without CE marking and without TÜV approval Medium: unknown Viscosity: unknown Flow rate: unknown Type, size and quantity of contamination unknown including the following documentation in German as a PDF by e-mail as follows: - User's manual with spare part identification for screen basket filter type DELTA-OW 2 00370048 DELTA-OV/OW Sieve Basket Type OV/OW-2"-2 1/2" 2021/13 2 pcs 0.00 0.00 101 fineness 560 μm nominal Material stainless steel 1.4571/1.4401 Filter area 484 cm² Net weight: approx. 0.35 kg installed in pos. 1 |
Where can I buy DELTA-OW/WB by Airpel in Japan?
You can purchase DELTA-OW/WB by Airpel from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the DELTA-OW/WB?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Airpel in Japan?
While we are not the official distributor or seller of Airpel in Japan, we source our products from reliable channels and offer you original Airpel equipment at competitive prices.
How can I access DELTA-OW/WB catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for DELTA-OW/WB on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for DELTA-OW/WB?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
