filter basket, type DELTA-OW/WB-S
as a double filter, DN150
Manufacturer Code: OWWB-600F-FSA-GEC
Housing material: cast iron EN-JL 1030
Inlet and outlet: DN150, drilled according to PN16 (EN1092-1)
Inline design, i.e. entrance and exit facing each other at the same height
max. allowable pressure PS: 16 bar
Operating overpressure: unknown
allowable max. temperature TS: 50°C
Operating temperature: unknown
Sealing material: FPM (for use from —20°C to +200°C)
Bushing: BS1400 LG2C bronze
Switch valves: BS1400 LG2C bronze
Sealing/storage of changeover valves: metallic
Internal machine parts: stainless steel 1.4305
Weight when empty: approx. 250 kg
Number of strainer baskets: 1 piece (per filter chamber)
***
Meaning of “FSA”:
- with closed holes for differential pressure gauges
- with connections for differential pressure measuring devices on the 1/4" BSP (G 1/4") connection flanges
Meaning of “GEC”:
- with ventilation holes in the 1/2" NPT filter covers with steel plugs
- with drain openings below the 1/2" NPT inlet with steel plug
- with sealed 1/4" NPT thread on the inlet side of the filter for a balancing valve
(not included)
- the filter is sprayed with anticorrosive fluid/lubricant
- without outer coating, just degreasing and a layer of red oxide primer as
Rust protection
***
Conformity assessment in accordance with Pressure Equipment Directive 2014/68/EU
Classification in accordance with Article 4, paragraph 3, “good engineering practice”
Fluid group 2, liquid (steam overpressure pD <= 0.5 bar)
without CE marking and without TÜV approval
Medium: unknown
Viscosity: unknown
flow rate: unknown
Nature, size, and amount of contamination unknown
including the following documentation in German as a PDF via email as follows:
- Operating manual with spare part identification for filter type DELTA-OW

DELTA-OW strainer basket type OW-6"
Fineness 2000 μm nominal
Material stainless steel 1.4571/1.4401
Filter area approx. 2065 cm²

Installed
