| BRAND | Buchi |
| Product | M-565 / order code 11058004 |
| Description | Fusion point M-565 |
| Internal code | YUS4743825 |
| Technical specification | Positions for fusion capillaries 3 Positions for boiling capillaries 1 Precision magnifying glass 1 Lens magnification 2.5x Color Display, TFT, 320 x 240, 3.5 ̋ Determination temperature range Environment + 10 °C to 400 °C Temperature resolution 0.1 °C Oven temperature accuracy of 0.5 °C/min ± 0.3 °C Melting point repeatability of 0.5 °C/min ± 0.1 °C Boiling point accuracy from 1.0 °C/min to 400°C: ± 0.5°C Temperature gradients, °C/min 0.1, 0.2, 0.5, 1, 1.5, 2, 2.5, 3, 5, 10, 20 Heating time (50 °C – 350 °C) to 25 °C ~ 4 min Cooling time (350 °C – 50 °C) to 25 °C ~ 13 min Electrical supply 100 - 240 V (± 10%) / 50 - 60 Hz Power consumption 150 W Storable methods for melting point 50 Storing Methods for Boiling Point 50 In accordance with methods of Pharmacopoeia PH. EUR., USP and JP Interfaces 1 x PS/2 1 x RS232 1 x USB Languages en/de/fr/it/es/ja/cn |
