| BRAND | Lowara |
| Product | LSN125-100-200S1VV1-7502 |
| Internal code | YUS3376084 |
| Weight | 935.2 |
| Technical specification | Materials: Impeller: alloy cast steel, 1.4408 Casing: alloy cast steel, 1.4408 casing cover: alloy cast steel, 1.4408 Shaft: alloy steel, 1.4021 shaft sleeve: Stainless Steel Wear rings: without (Standard) Shaft seal: S1..1 Cyclone seal chamber with smooth shaft sleeve Shaft seal MG912 Single seal rubber bellow, unbalanced Materialcombination: BQ1EGG Fluid: Water, pure Temperature: 4 °C Density: 1,000 kg/dm³ Viscosity: 1,569 mm²/s Capacity: 256,0 m³/h Head: 70,0 m Power: 60,9 kW Efficiency: 80,6 % NPSH: 6,26 m Speed: 3550 1/min Req. Motor power: 71,9 kW Suction flange: DN 125, PN16, EN 1092 (IC) horizontal at centerline Discharge flange: DN 100, PN16, EN 1092 (IC) vertical at top-centerline max. Casing pressure: 16 bar Suction-/Systempressure: 0,10 bar Lubrication:Oil (Standard) Oilsump cooling: without Oilsump cooling Constant level oiler: without constant level oiler, with sight glass Labyrinth seals: without Motor Brand: WEG Type: W22 - 280 S/M - 75kW Nom. power: 75 kW Nom. current: 78,6 A Voltage: 660 V Frequency: 60 Hz Speed: 3570 1/min Design: IM B3 Size: 280 S/M Isolation class: F Protection class: IP55 Total weight: 935,2 kg Painting LSN Standard Type: Extended standard coating level 2 Mark: Standard LSN Application: Pumps and machines for use in wet rooms or outside Temperature: max. 140°C Preparation: Sandblasting SA 2 1/2 acc. DIN 55928, Part 4 Primer coat: Two component Epoxy Resin - Zinc Phosphate Primer: Remoplast RT Colouring Oxydrot Thickness: 40 my Finish coat: Pump Chlorinated Rubber Typ Firewood 781 Thickness: 50 my Finish coat: Frame and Motor Epoxyharz-Polyamino-Amidaddukt with Micaceous iron ore, Remoplast UVC Thickness: 40 my Colour Pump: RAL 5010 blue Colour Frame: RAL 5010 blue Colour Motor: RAL 5010 blue Colour Coupling guard: RAL 5010 blue stainless without painting Boxing P4 - covered in foil (0.7-5m³) Goods covered in foil 0,3mm and put into a fully closed wooden box made from 3/4" (standard) or 1" pine wood boards. Pine wood blocks 80 x 100 mm underneath the base boards allow the whole unit to be transported by means of a forklift. This type of boxing is stackable. Goods secured against shifting during transportation by means of bolts or styrofoam chips. Application: ship (container), airfreight, truck For outdoor storage up to max. 3 month Brutto-Volumen: 0,95839 mm m³ |
Where can I buy LSN125-100-200S1VV1-7502 by Lowara in Japan?
You can purchase LSN125-100-200S1VV1-7502 by Lowara from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the LSN125-100-200S1VV1-7502 ?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Lowara in Japan?
While we are not the official distributor or seller of Lowara in Japan, we source our products from reliable channels and offer you original Lowara equipment at competitive prices.
How can I access LSN125-100-200S1VV1-7502 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for LSN125-100-200S1VV1-7502 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for LSN125-100-200S1VV1-7502 ?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
