Prices JTD920S-1E1B1-X1XX2-A2C7U299 SHW034-002 Yamatake - Azbil Japan

BRAND	Yamatake - Azbil
Product	JTD920S-1E1B1-X1XX2-A2C7U299 SHW034-002
Description	Electric Standard Differential pressure type with Manifold
Internal code	YUS5105008
Weight	6
Technical specification	with MVG1-2SA-X-A Range 1150-750mmH2O Electric Standard Differential pressure type with Manifold Range: -1150 to 750 mmH2O Measuring span : 0.5 to 100kPa (50 to 10160mmH2O) 4-20mA output Drain plugs and wetted parts : SUS316 Meterbody cover : SCS14A Fill Fluid : regular type ( Silicone oil) Rc 1/2, bottom connection Bolts/Nuts : carbon steel Electrical connection : G1/2 watertight Built-in indicating smart meter :0 to 100 % linear scales With mounting bracket : SUS304 (Flat Form Bracket) External Zero adjustment Process connection ; reverse NON SI Unit Copy of data on commstaff damping : 2 sec. MVG1-2SA-X-A : 3 ways Manifold Valve Standard type Body : Stainless Steel (SUSF316) Jointing Bolts for Instrument : Stainless Steel (SUS304) Operating pressure range : -1.198 to 13.7 Mpa {- 1 to + 140kgf/cm2} Operating temperature range : - 40 to + 120°C Test pressure : 20.6MPa{210kgf/cm2} No Extension Pipes No option

Yamatake - Azbil - JTD920S-1E1B1-X1XX2-A2C7U299 SHW034-002 referenced Electric Standard Differential pressure type with Manifold product produced by high technology.
JTD920S-1E1B1-X1XX2-A2C7U299 SHW034-002 is the result of a far more developed technology compared to similar regular products. We are one of the few companies which can present an offer for this product. It produced result of tests of laborotory for years. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy JTD920S-1E1B1-X1XX2-A2C7U299 SHW034-002 by Yamatake - Azbil in Japan?

You can purchase JTD920S-1E1B1-X1XX2-A2C7U299 SHW034-002 by Yamatake - Azbil from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the JTD920S-1E1B1-X1XX2-A2C7U299 SHW034-002?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Yamatake - Azbil in Japan?

While we are not the official distributor or seller of Yamatake - Azbil in Japan, we source our products from reliable channels and offer you original Yamatake - Azbil equipment at competitive prices.

How can I access JTD920S-1E1B1-X1XX2-A2C7U299 SHW034-002 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for JTD920S-1E1B1-X1XX2-A2C7U299 SHW034-002 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for JTD920S-1E1B1-X1XX2-A2C7U299 SHW034-002?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
