Prices 37100 IFE4R24 Elettrotec Japan

BRAND	Elettrotec
Product	37100 IFE4R24
Description	electric flow switch
Internal code	YUS114266
Weight	0.485
Custom code	90261081 / 90268020
Technical specification	ECO 3 - 24 l/min Electric flow switch adjustable Contact type: Opener - opens the contact when the switch point falls below the set switching point. For media with low viscosity, such as water and water/glycol mixtures Material: nickel-plated brass Maximum working voltage: 220V - 50Hz Maximum power load in DC mode: 20W Maximum current load in AC mode: 20VA Breakdown voltage: 300V Protection class: IP65 Flow rate: 3 - 24 l/min Max. pressure: 50bar Maximum pressure loss with H2O: 0.5bar Working temperature: -10°C... +80°C Installation length: 115mm Connection thread: G1/2" Installation position: vertical - max. inclination 15° Flow direction: from bottom to top In accordance with CE 89/336 The flow switch must be installed at least 50 mm away from components that influence the magnetic field.

Elettrotec - 37100 IFE4R24 referenced electric flow switch product produced by high technology.
37100 IFE4R24 is the result of a far more developed technology compared to similar regular products. All of the listed products are with guaranteed origin and high quality. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy 37100 IFE4R24 by Elettrotec in Japan?

You can purchase 37100 IFE4R24 by Elettrotec from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the 37100 IFE4R24?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Elettrotec in Japan?

While we are not the official distributor or seller of Elettrotec in Japan, we source our products from reliable channels and offer you original Elettrotec equipment at competitive prices.

How can I access 37100 IFE4R24 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 37100 IFE4R24 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 37100 IFE4R24?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
