Prices IF4VE16/A Elettrotec Japan

BRAND	Elettrotec
Product	IF4VE16/A
Description	Electrical flow switch
Internal code	YUS312116
Weight	1
Custom code	9026108100
Technical specification	710-545-01900 36275A IF4VE16/A Aluminium flow switch electr./ opt. 2-16 l/min Adjustable electric flow switch with visual display Contact type: Opener - opens the contact when it falls below the set switching point. Viscosity range: 0 - 6 cSt Material: aluminum Max. working voltage: 220V - 50Hz Max. current load in DC mode: 60W Max. current load in AC mode: 60VA Breakdown voltage: 300V Protection class: IP65 Flow rate: 2 - 16l/min Max. pressure: 15bar Working temperature: -10°C... +100°C Installation length: 167mm Connection thread: G1/2" Installation position: vertical - max. inclination 15° Flow direction: from bottom to top In accordance with CE 89/336 The flow switch must be mounted at least 50 mm away from components affecting the magnetic field become.

You can find the current prices belongs to Elettrotec - IF4VE16/A coded Electrical flow switch product. You can ask all the codes and references except IF4VE16/A too. We are one of the few companies which can present an offer for this product. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for IF4VE16/A Elettrotec . Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.
