Prices F092961 Niezgodka Japan

BRAND	Niezgodka
Product	F092961
Internal code	YUS5010571
Weight	4.5
Custom code	84814010
Technical specification	F092961 Safety valve with component mark and CE mark according to PED Valve type: 19.2 Model size: II Material: 1.4571/1.4581 do/Seat diameter: 25 mm Process connection: DIN 32676 clamp, for pipes in accordance with DIN 11866 series C Admission: DN/OD 2 Outlet: DN/OD 2 valve head: A Cone seal: PTFE (USP/ADI/FDA) other seals: EPDM (USP/FDA/ADI) Spring No.: 2490 Options: EGH Adjusted overpressure: 5.0 bar (g) Pressure level: PN 16 EGH: Surfaces in contact with media in the entrance area with surface quality Ra = 0.4 μm Medium: steam Temperature: 150°C Throughput: max 874 kg/h Clamp Dk: 64.0 mm Di connector: 47.5 mm Side length SE: 70.0 mm Side length SA: 70.0 mm Note: Custom made - no returns possible. The confirmed ADI seals include additional cleaning of the entire valve (free from animal ingredients and free of oil and fat). Then, on to the required A special lubricant (NSF-H1/ADI-free) is applied to areas. Note: Design as valve number F32461, but with spring according to the latest spring table Customs tariff number: 8481 40 10 Country of origin: DE

Niezgodka - F092961 referenced product produced by high technology.
You can provide the all references you look for in endustrial accessories in our company with our unique product range. We are one of the few companies which can present an offer for this product. It produced result of tests of laborotory for years. We present you the most competative price and delivery time on F092961 referenced product.

Where can I buy F092961 by Niezgodka in Japan?

You can purchase F092961 by Niezgodka from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the F092961?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Niezgodka in Japan?

While we are not the official distributor or seller of Niezgodka in Japan, we source our products from reliable channels and offer you original Niezgodka equipment at competitive prices.

How can I access F092961 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for F092961 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for F092961?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
