| BRAND | Niezgodka |
| Product | F071281 |
| Description | Stainless steel pressure reducing valve |
| Internal code | YUS4200790 |
| Custom code | 84811019 |
| Technical specification | without CE mark according to PED (Art. 4/3) -20.00% piece Valve Type: 70.2 Series SKS-CL Size: I Material: 1.4301/1.4571 piston plate: ø 64 mm Process connection: Terminal DIN 32676, for pipes according to DIN 11866, Series C Admission: DN/OD 1 Outlet: DN/OD 1 Tapered Gasket: EPDM (FDA) other gaskets: EPDM (FDA) /PTFE (FDA) Spring No: 306 Options፦ Code: I-K064-F306-EPDM (FDA) Kvs-value: 3.2 m³/h Inform P1:4.0 bar (g) Low pressure P2: (1.0) 1.5 - 3.0 bar (g) Pressure Rating: PN 16 Medium: no information Throughput: not specified Temperature: 20°C Fastener Dk: 50.5 mm Fastener Di: 22.1 mm Closing pressure reducing valve at 0 consumption, wetted inner surfaces with Ra = 2.6 µm (standard), max. damping temperature 140°C, housing with 2 pressure gauge connection holes G 1/4 |
