| BRAND | Niezgodka |
| Product | F059961 |
| Description | Pressure reducing valve |
| Internal code | YUS3761465 |
| Weight | 37 |
| Custom code | 84811019 |
| Technical specification | Stainless steel pressure reducing valve with CE mark according to PED Valve type: 70.2 series SKS-F Size: IIIB Material: 1.4435 / 1.4404 Butt plate: ø 119 mm Process connection: Flanges according to DIN 2633 Inlet: DN 80 PN 16 form C Outlet: DN 80 PN 16 form C Cone seal: EPDM (FDA) other seals: EPDM (FDA) / PTFE (FDA) Spring No.: 356 Options: Code: IIIB-K119-F356-EPDM (FDA) Kvs value: 28.5 m³/h Inlet pressure P1: max. 16.0 bar(g) Low pressure P2: 1.5 bar(g) Pressure level: PN 16 Medium: not specified Throughput: not specified Temperature: no information Pressure reducing valve closing at 0 consumption, inner surfaces in contact with the product with Ra = 2.6 µm (standard), max. steaming temperature 140°C, housing with 2 manometer connection bores G 1/4 Customs tariff number: 8481 10 19 Country of origin: DE Note: The version corresponds to the valve no. F01684 |
