| BRAND | Niezgodka |
| Product | F028824 |
| Internal code | YUS4173061 |
| Custom code | 84811019 |
| Technical specification | Stainless steel pressure reducing valve with CE mark according to PED Valve type: 70.2 SKS-GA series Size: III Material: 1.4435 / 1.4404 Piston plate: ø 99 mm Process connection: screw connection according to DIN 11851 Inlet: DN 50 threaded connector Outlet: DN 50 threaded connector Cone seal: EPDM (FDA) other seals: EPDM (FDA) / PTFE (FDA) Nib no .: 325 Options: - Code: III-K099-F325-EPDM (FDA) Kvs value: 13 m³ / h Inlet pressure P1: 10.0 bar (g) Downstream pressure P2: 1.0 bar (g) Pressure level: PN 16 Medium: CO2 Throughput: not specified Temperature: 20 ° C Pressure reducing valve closes at 0 consumption, inner surfaces in contact with the product with Ra = 2.6 µm (standard), maximum damping temperature 140 ° C, housing with 2 pressure gauge connection holes G 1/4 |
