Prices F034991 Niezgodka Japan

BRAND	Niezgodka
Product	F034991
Description	pressure reducing valve
Internal code	YUS274085
Weight	1
Custom code	8481 10 19
Technical specification	Valve type: 70.2 series SKS-GA Size: I Material: 1.4301/1.4571 piston plate: ø 64 mm Process connection: pipe fitting according to DIN 11851 Inlet: DN 25 threaded connector Outlet: DN 25 threaded connector Cone seal: PTFE (FDA) other seals: EPDM (FDA)/PTFE (FDA) Nib no.: 305 options: - SKU: I-K064-F305-PTFE/EPDM (FDA) Kvs value: 3.5 m³/h Form pressure P1:4.0 bar (g) Reduced pressure P2: (0.8) 1.0 - 2.0 bar (g) Pressure stage: PN 16 Medium: steam, 150 °C Throughput: not specified Pressure reducing valve closes at zero consumption, internal surfaces in contact with product with Ra = 2.6 μm (standard), max. damping temperature 150°C, housing with 2 gauge connection holes G1/4 Equivalent to serial number F24824 Stainless steel without CE mark according to PED (Art. 4/3)

You can find the current prices belongs to Niezgodka - F034991 coded pressure reducing valve product. You can ask all the codes and references except F034991 too. All of the listed products are with guaranteed origin and high quality. It produced result of tests of laborotory for years. Contact us if you are looking for alternative price of F034991 .
