| BRAND | Aviteq |
| Product | Controller for - 3000003160 |
| Internal code | YUS4914261 |
| Custom code | 85365003 |
| Technical specification | SCE-DN50-2 380.. 420V 50HZ 15A IP20 CONTROL 200 x 62 x 200 mm (HxWxD) VIBTRONIC® -S controller for connecting AVITEQ vibrating conveyors. The swing width of the conveyor can be adjusted continuously on the connection device Become. Delivery rate adjustment range from close to 0 to 100%. With a complete set of potentiometers for manual swing range adjustment. Electromagnetic compatibility (EMC) in accordance with the applicable EC Directive checked. To protect the thyristors in the controller, there is a Install super-fast protection (Superflink or Ultrarapid). Vibration rate SC/E.. 50... 3,000 min-1 Version for installation in on-site control cabinets Perforated steel housing RAL 5018 powder-coated Power cable without Network fluctuation compensation ± 10%, the oscillation width remains constant Proportional change in the setpoint Switch release (continuous contact, potential-free) or Voltage signal +24 V (DC) Inputs to external external control variables 0-10V (DC), 0-20mA (DC), 4-20mA (DC) Remote monitoring outputs, relay output Main dimensions approx. H200 x W62 x D200mm Protection class IP20 in accordance with DIN EN 60529 Weight approx. 2.2 kg The swing width of the conveyor can be continuously adjusted on the connection device Delivery rate adjustment range from close to 0 to 100%. With a complete set of potentiometers for manual swing range adjustment. Electromagnetic compatibility (EMC) tested in accordance with the applicable EC Directive. To protect the thyristors in the controller, there is a super-fast to install protection (Superflink or Ultrarapid) |
