| BRAND | Technotrans |
| Product | cs 180e.1 |
| Internal code | YUS4838160 |
| Weight | 59 |
| Custom code | 8419 89 98 |
| Technical specification | Key features: - Membrane keyboard with 7-segment display - LongLife stainless steel cartridge heater - Durable magnetically coupled peripheral stainless steel pump - Tankless device for minimal oxygen uptake Operating fluid, water heat transfer medium Flow temperature max. 180 °C Required water quality https://www.technotrans.de/produkte/filtrieren-und-separieren/wasserqualitaet Continuous heating via solid state semiconductor relays Heating capacity 9 kW Indirect cooling, WT 7/02 Cooling regulation solenoid valve Cooling capacity 40 kW at circulating medium temperature 130 °C at a cooling water temperature of 15 °C WP 60 MK operating pump Delivery volume max. 60 l/min Delivery pressure max. 6.0 bar Scheme BasicControl 32 bit controller ports Operating voltage 400V/50Hz/3Ph+Pe 3.0 m supply line with CEE plug 16 A Circulating medium connections forward/return G 1/2" Cooling water connections flow/return G 1/4” Cooling water pressure 3-4 bar Control cabinet protection class IP 54 Dimensions (LxWxH) 674x356x607 mm Side panels RAL 260 40 45 LED blue Case/front panel RAL 7012 basalt grey Ambient temperature max. 40 °C Volume DIN 45635T1, LpA 1m <70 dB (A) Standard equipment: Service: - Membrane keyboard with 7-segment display Heating: - “longlife” stainless steel heating cartridge Pumping technology: - Durable magnetically coupled peripheral stainless steel pump Measurement technology/ Alerting: - Electronic temperature measurement in advance - Audible and visual alarm Other equipment features: - “Tankless” device for minimal oxygen uptake - Medium-contact components made of corrosion-resistant materials - Cooling via solenoid valve - Good accessibility for maintenance work through removable cladding sheets - Interface port on the front of the device - Optimized placeability due to compact design - IP 54 control cabinet - Strainer in the coolant flow The following options are added to the standard equipment: (Options may replace standard equipment) - Profibus interface - rubber bumpers |
Where can I buy cs 180e.1 by Technotrans in Japan?
You can purchase cs 180e.1 by Technotrans from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the cs 180e.1?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Technotrans in Japan?
While we are not the official distributor or seller of Technotrans in Japan, we source our products from reliable channels and offer you original Technotrans equipment at competitive prices.
How can I access cs 180e.1 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for cs 180e.1 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for cs 180e.1?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
