Prices CFIB - 2 - MA - 35H - ET - S - 0 CeTech Japan

BRAND	CeTech
Product	CFIB - 2 - MA - 35H - ET - S - 0
Internal code	YUS4878038
Weight	5
Custom code	90330000
Technical specification	GLOBTOP case mod. CFIB in 316L stainless steel, with open/closed position indicator for rotary valves (maximum resistance to chemical and atmospheric agents) ATEX certification (BVI 19 ATEX 0006): Ex II 2 GD — Ex db IIC T6/T5/T4 Ex tb IIIC T85/T100/T135°C (Tamb. from -50°C to +60/+80/+100°C) - Cable entry: n. 3 3/4 “holes npt-f - Terminal block: 6 terminals plus ground connection (option 12 terminals) - Degree of protection: IP66/67/67M (with shaft rotation test) - Treatment: electropolishing - Position indicator: red-green three-dimensional dome - Shaft: namur coupling — 316 stainless steel material - Each case is equipped with n. 2 GO SWITCH with the following characteristics: - Passive type 30 Mod. 35 Hermetic series magnetic window (without power supply and without reed contacts) - Mechanical contact (snap action & dry contact): gold-plated SPDT in silver-cadmium; hermetic - Contact flow: 4A AC 120V AC, 2A AC 240V AC and 3A DC 24V DC resistive load - Sensitive distance: 3 mm. (with iron feedback) - Differential (hysteresis): 3 mm. (with iron feedback) - Response time: 8 milliseconds - Working temperature: see enclosure certification table - Housing material: cupronickel - nr.4 connection conductors insulated in PVC 105°C

CeTech - CFIB - 2 - MA - 35H - ET - S - 0 referenced product produced by high technology.
CFIB - 2 - MA - 35H - ET - S - 0 became irreplaceable of foundations. CFIB - 2 - MA - 35H - ET - S - 0 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Our company can make an offer even if we do not distributor of Japan. We present you the most competative price and delivery time on CFIB - 2 - MA - 35H - ET - S - 0 referenced product.

Where can I buy CFIB - 2 - MA - 35H - ET - S - 0 by CeTech in Japan?

You can purchase CFIB - 2 - MA - 35H - ET - S - 0 by CeTech from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the CFIB - 2 - MA - 35H - ET - S - 0?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of CeTech in Japan?

While we are not the official distributor or seller of CeTech in Japan, we source our products from reliable channels and offer you original CeTech equipment at competitive prices.

How can I access CFIB - 2 - MA - 35H - ET - S - 0 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for CFIB - 2 - MA - 35H - ET - S - 0 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for CFIB - 2 - MA - 35H - ET - S - 0?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
