| BRAND | BFI AUTOMATION |
| Product | 6013-2063-00 - CFC2000IR2-L |
| Description | OE converter |
| Internal code | YUS4902932 |
| Weight | 1.6 |
| Custom code | 84169000 |
| Technical specification | Relay and 0/4-20mA output Two-channel compact system for continuous monitoring of gas and oil burners of any capacity with additional frequency analysis for improved selectivity. The compact OE transducer is equipped with a semiconductor dual sensor with spectral sensitivity in the UV and IR range, which can be set separately. Electronic self-monitoring ensures safe operation. Flame intensity and the status of the flame relay are indicated by LEDs. The safety switch-off time can be predefined via a jumper and set by software (1-5s). Sensitivity, ON/OFF level and switch-on delay are set by software. Online frequency analysis and visualization of the flame radiation is possible with the BFI software. The compact flame monitor is housed in a 0E converter housing for connecting a BFI fiber optic cable (FO cable) or lance (FO lance). Further technical details: Two separate and adjustable sensitivity levels Potential-free changeover contact for the flame ON/OFF signals. Flame relay: potential-free changeover contact max. 48V switching voltage. Further technical details: Two separate and adjustable sensitivity levels Flame relay: potential-free changeover contact max. 48V switching voltage, max. 1A switching current max. 30W switching capacity, Flame signal output: 0/4-20mA (Ra <250 Ohm) Supply voltage: 24V DC Current consumption: approx. 200 mA Spectral range: 300-2700nm Viewing angle: 2.7° Self-test: once in 800ms Ambient temperature: -20 to + 70°C Data transmission: RS232/infrared interface Electrical connection: Harting plug 90° Dimension [mm]: L120xW122xH80 Housing: Aluminum, RAL5010, IP66 ATEX zone2: I 3G Ex ec nC II T4 Gc Safety Integrity Level: SIL3 |
Where can I buy 6013-2063-00 - CFC2000IR2-L by BFI AUTOMATION in Japan?
You can purchase 6013-2063-00 - CFC2000IR2-L by BFI AUTOMATION from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the 6013-2063-00 - CFC2000IR2-L?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of BFI AUTOMATION in Japan?
While we are not the official distributor or seller of BFI AUTOMATION in Japan, we source our products from reliable channels and offer you original BFI AUTOMATION equipment at competitive prices.
How can I access 6013-2063-00 - CFC2000IR2-L catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 6013-2063-00 - CFC2000IR2-L on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 6013-2063-00 - CFC2000IR2-L?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
