Prices CEW58M-00044 TR Electronic Japan

BRAND	TR Electronic
Product	CEW58M-00044
Description	ENCODER,STRING POT
Internal code	YUS5024748
Weight	1.6
Technical specification	Pulley sensor CEW58M4096/4096 LJU (NEW:CEW582M-10044) ATTENTION: outlet with replacement Total weight 1.600 kg Statistical product number: 90318020 Country of origin: GERMANY Region of origin: Baden-Württemberg AL:N ECCN:N Technical details appendix Order number description CEW58M-00044 CEW58M4096/4096 LJU (NEW:CEW582M-10044) STEP COUNT 4,096,000 REVOLUTIONS 4,096,000 LJU-BUS INTERFACE BINARY CODE SUPPLY VOLTAGE 11-27V RS485 OUTPUT LEVEL PROTECTION CLASS IP65 WORKING TEMPERATURE 0-60°C SHAFT DESIGN 12H7 HOLLOW SACK SHAFT CONNECTION TYPE 1X4P.M12 SOCKET (A-COD.) 1X5P.M12 PLUG (A-COD.) RADIAL CONNECTION DIRECTION PIN ASSIGNMENT NUMBER K303=3659+3556 MATCHING PLUG NO OPTION ENC WHEN EXCERPT V. ROPE: STG. VALUES TRANSMITTER AT HALF CAPACITY INK TRACKS 1024IMP (11-27V) K1+K2 ME-WDS-5000-P115-M 5.0M CENTER PREPROGRAM = 8388608 PRESET 1 PRESET VALUE1 = 8388608 CABLE LENGTH SENSOR SLG ITEM NUMBER 40730008 DRAWING NO. 04-CEW58M-M0034 VERSION NO. 000 SOFTNR 4376E6 DOCUMENTATION NO. DOCUMENTS AL: N ECCN: N SLG CABLE LENGTH 5000 mm SLG TRANSLATION 315.60... 316.00 mm/RPM SLG LINEARITY +/ -0.02% (tol. at 0-1m: ±5mm) SLG SHAFT DESIGN 12GL/24 SLG HOUSING MATERIAL ALUMINUM SLG TEMPERATURE RANGE -20°C.. +80°C SLG PROTECTION CLASS IP54/IP65 OUTLET AT THE BOTTOM SLG SPRING FORCE min.3n/ max.7.5N SLG B10 VALUE 450,000 at 52,800 cycles p.a. SLG ROPE DIAMETER 0.45 mm SLG EXTENSION ANGLE max. +/-3° SLG PULLEY NO SLG SERVICE LIFE max. 10 years

TR Electronic - CEW58M-00044 referenced ENCODER,STRING POT product produced by high technology.
If you need other products from TR Electronic, please send us an inquiry by e-mail. It distinguishes with price and quality among the similar products. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for CEW58M-00044 TR Electronic . Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy CEW58M-00044 by TR Electronic in Japan?

You can purchase CEW58M-00044 by TR Electronic from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the CEW58M-00044?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of TR Electronic in Japan?

While we are not the official distributor or seller of TR Electronic in Japan, we source our products from reliable channels and offer you original TR Electronic equipment at competitive prices.

How can I access CEW58M-00044 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for CEW58M-00044 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for CEW58M-00044?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
