| BRAND | Bauer |
| Product | BS06-61U/DHE07LA4-ST/SP |
| Description | worm geared motor |
| Internal code | YUS4600759 |
| Weight | 14.8 |
| Custom code | 85015100 |
| Technical specification | Material number 30679322 BCAS article number 189F4736 Motor power: 0.25 kW Speed of the AW: 9.4 r/min Torque (max. permissible): 106 Nm Operating factor fB: 1.0 Lineup: H1/V2 Terminal box location: II/B Corrosion protection: standard Paint: 1K primer Dimensional image: BS06 Catalogue: B 2010 Net weight per piece: approx. 15 kg Additional/special versions: Type H1 inclined by 45° according to design V2. Gearbox design: Type: BS06 2-stage worm gear version code 61U with foot thread on the bottom PTO shaft on transmission side V (d: 25 mm) Overall reduction ratio i: 146.8 Additional/special versions: Lubricant grade: PGLP 220 Engine design: Type: three-phase squirrel cage motor DHE07LA4-ST Rated speed: 1375 r/min voltage: 400 V Stator connection: Y frequency: 50 Hz Rated current: 0.76 A power factor cos phi: 0.68 Efficiency: IE2 - 69.4% (according to EN 60034-2-1) Heat class: F IP protection class according to EN 60529: IP 65 IC cooling type according to EN 60034-6: IC 411 Terminal box: TBS112 Design according to DIN VDE 0530-1/EN 60034-1 Additional/special versions: Harting plug connection HAN 10 ES According to dimension diagram TBS11.-01-A3 and connection diagram HS10000000/01: Mounting housing 09 300 100 305 - 1 bracket pin insert 09 330 102 616 sleeve housing - female insert - cover 09 300 105 412 |
Where can I buy BS06-61U/DHE07LA4-ST/SP by Bauer in Japan?
You can purchase BS06-61U/DHE07LA4-ST/SP by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the BS06-61U/DHE07LA4-ST/SP?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Bauer in Japan?
While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.
How can I access BS06-61U/DHE07LA4-ST/SP catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for BS06-61U/DHE07LA4-ST/SP on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for BS06-61U/DHE07LA4-ST/SP?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
