| BRAND | Bauer |
| Product | BS06-31V/D08LA62-ZW-S/ESX010A5/SP (188J3147) |
| Description | Worm gear motor with single-disc spring brake |
| Internal code | YUS3421478 |
| Weight | 19.3 |
| Custom code | 85015100 |
| Technical specification | Material number 30502581 BCAS item number 188J3147 BS06-31V/D08LA62-ZW-S/ESX010A5/SP Description Article number: 188J3147 Worm gear motor with single-disc spring brake BS06-31V/D08LA62-ZW-S/ESX010A5/SP Motor output: 0.20/0.63-S3-25/ 75% kW AW speed: 15.0/44.0 r/min Torque: 76/92 Nm Operating factor fB: 1.05/0.87 Line-up: H2/V2 Terminal box location: IV/ A Corrosion protection: standard Paint: RAL 7031 Dimension picture: BS06 Catalogue: DG 07 Additional/special versions: Total paint thickness 40 μm Design H2 inclined by 30° according to design V2. SondaUSF engine in accordance with ZN.D08-00-ES-A3-K001. Transmission design: Type: BS06 2-stage worm gear Version code 31V with standard flange on the front side (d: 140 mm) Pinion shaft on transmission side V Total reduction i: 64.06 Additional/special versions: Lubricant type: PGLP 220 Special working shaft in accordance with ZN.BS06-30-A3-K19. (d x l): 20 mm x 50 mm) BAU2539004 Special gear housing in accordance with ZN.BS06/1-01-A1-AL P.1B. BAU2515377 foot thread on all sides Special flange transmission according to ZN.FA140/73-A2-K5. BAU2548089 Engine version: Type: three-phase cage rotor motor with pole switching D08LA62-ZW-S Rated speed: 930/2800 r/min Voltage: 400 V Stator circuit: Y/Y Frequency: 50 Hz Rated current: 1.14/1.71 A Cos phi power factor: 0.64/0.93 Warmth class: F IP protection class in accordance with EN 60529: IP 65 IC cooling type in accordance with EN 60034-6: IC 411 Terminal box: KAG2 Design in accordance with DIN VDE 0530-1/EN 60034-1 Additional/special versions: Pole switchable with two separate stator windings 2. Shaft end in accordance with ZN.D08-31-EG-A3-K2. BAU2707932 With glued-in cylinder screw M8x16 DIN 6912 BAU1402391 Brake design: working brake under the fan cover Type: Single disc spring brake ESX 010 A 5 Setting value: 5.0 Nm IP protection class in accordance with EN 60 529: IP 65 Coil voltage: 103 V coil current: 0.31 A Additional dimensions: N-BR-ZW-VK Cable version, connection ends of the magnetic coil connected to the rectifier in the motor terminal box. With standard rectifier installed in the motor terminal box Type: SG 3.575 B Supply voltage AC: 220.. 230 V (50/60 Hz) Connection current: 0.22 A DC output: 103 V |
Where can I buy BS06-31V/D08LA62-ZW-S/ESX010A5/SP (188J3147) by Bauer in Japan?
You can purchase BS06-31V/D08LA62-ZW-S/ESX010A5/SP (188J3147) by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the BS06-31V/D08LA62-ZW-S/ESX010A5/SP (188J3147)?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Bauer in Japan?
While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.
How can I access BS06-31V/D08LA62-ZW-S/ESX010A5/SP (188J3147) catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for BS06-31V/D08LA62-ZW-S/ESX010A5/SP (188J3147) on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for BS06-31V/D08LA62-ZW-S/ESX010A5/SP (188J3147)?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
