| BRAND | Bauer |
| Product | BS04-74V/DV04LA4 / 30675299 |
| Description | Helical Geared Motor |
| Internal code | YUS4618862 |
| Weight | 3.9 |
| Custom code | 85015100 |
| Technical specification | Material number 30675299 BCAS Article number 189F4018 BS04-74V/DV04LA4 Description screw gear motor BS04-74V/DV04LA4 Motor power: 0.06 kW Speed of the engine: 3.5/4.2 r/min Torque (max. allowable): 45.0/45.0 Nm operating factor fB: 1.0/1.0 Lineup: H4 Terminal box location: II/A Corrosion protection: standard Painting: RAL 7031 Dimension diagram: BS04 Catalogue: DG 07 Net weight per piece: approx. 3.9 kg Additional/special versions: With 2nd performance chip loose as an accessory pack Rating plates stamped with 220-240/380-420 V 50Hz, 220-280/380-480V 60Hz Gearbox design: Type: BS04 2-stage screw gearbox Design code 74V C flange with threaded holes on the front side Hollow shaft with spring groove (d: 20 mm) Total reduction i: 391.3 Additional/special versions: Lubricant grade: PGLP 220 U17b hollow wave paint plug installed Engine design: Type: DV04LA4 three-phase cage runner motor Design speed: 1350/1620 r/min Voltage: 200-280/380-480V Stator circuit: D/Y Frequency: 50/60 Hz Rated current: 0.78/0.45 A cos phi power factor: 0.51 Warmth class: F IP protection class according to EN 60034: IP 54 IC cooling type according to EN 60034-6: IC 411 Terminal box: KAG1 Design in accordance with DIN VDE 0530-1/EN 60034-1 Please note: transmission The rated power of the motors is primarily in conjunction with four-stage and multi-stage transmissions, in some cases abundantly dimensioned. In these cases, the rated current does not set a standard for represents transmission load and cannot be used as overload protection for the transmission. In Manchen In cases, the type of loading the work machine can in principle rule out an overload. In In other cases, it is useful to install the transmission by mechanical equipment (e.g. slip clutch, slip hub, etc.). The maximum allowable torque M2 in continuous operation as stated on the transmission's rating plate is decisive. In the case of transmissions with torque support by means of a flange or torque support, the side of the torque support must be provided on the side of the transverse force introduction via the working shaft! Divergent versions must be questioned in the factory. motor Motor connection is made via CAGE-CLAMP (cage tension spring technology)! CAGE CLAMP is a registered trademark of WAGO Engine protection on site by customer. Stat. Product number 85015100 Country of origin Slovakia Operating manual GB net weight 3,900 KG |
Where can I buy BS04-74V/DV04LA4 / 30675299 by Bauer in Japan?
You can purchase BS04-74V/DV04LA4 / 30675299 by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the BS04-74V/DV04LA4 / 30675299?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Bauer in Japan?
While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.
How can I access BS04-74V/DV04LA4 / 30675299 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for BS04-74V/DV04LA4 / 30675299 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for BS04-74V/DV04LA4 / 30675299?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
