Prices BS03-74VH/DHE08LA4-TF-G-K2A005 Bauer Japan

BRAND	Bauer
Product	BS03-74VH/DHE08LA4-TF-G-K2A005
Description	gearmotor complete with control unit
Internal code	YUS4796767
Weight	12
Custom code	85015100
Technical specification	Material number 30599665 BCAS item number 188Y0579 Article number: 188Y0579 Eta worm gear motor BS03-74VH/DHE08LA4-TF-G-K2A005 Motor power: 0.55-S9 kW Speed of the AW: 75 r/min Torque: 53 Nm Operating factor fB: 1.05 Line-up: H1 Terminal box location: I/A1 Corrosion protection: standard Paint: 1K primer Measurement image: BS03 Catalogue: DG 07 Transmission design: Type: BS03 1-stage worm gear Model number 74VH C-flange with threaded holes on front and rear sides hollow shaft with keyhole (d: 20 mm) Total reduction i: 19.00 Additional/special versions: Lubricant type: PGLP 220 Motor design: Type: Three-phase squirrel cage motor DHE08LA4-TF-G-K2A005 Rated speed: 1420 r/min Voltage: 350 V Stator circuit: Y frequency: 50 Hz Rated current: 1.60 A Power factor cos phi: 0.73 Warmth class: F IP protection class according to EN 60529: IP 65 IC cooling type according to EN 60034-6: IC 411 Terminal box: eTAK20 Design in accordance with DIN VDE 0530-1/EN 60034-1 Additional/special versions: With built-in thermistors for shut-off according to additional connection diagram Z010.1040-1 Operation via an integrated frequency converter: in the frequency range Hz: 5 15 50 Frequency converter technical data Type: eTAK2.0 Model: K2A005 Power: 0.55 kW - frame size 1 Power plug: QuickON Comm. -Unit: with standard I/O Parameterization: standard efficiency: The motor and frequency converter combinations (PDS) are classified in accordance with IEC 61800-9-2 and meet the IES 2 system efficiency class With built-in incremental encoder Type: EIL580 Pulse frequency (Imp/Umdr): 256 DC supply voltage: 8.. 30 V HTL Output signals: A; B; N+Inv Power consumption: max. 70 mA IP protection class according to EN 60 529: IP 65 Express speedometer connection via plug

Bauer - BS03-74VH/DHE08LA4-TF-G-K2A005 referenced gearmotor complete with control unit product produced by high technology.
BS03-74VH/DHE08LA4-TF-G-K2A005 became irreplaceable of foundations. BS03-74VH/DHE08LA4-TF-G-K2A005 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. BS03-74VH/DHE08LA4-TF-G-K2A005 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy BS03-74VH/DHE08LA4-TF-G-K2A005 by Bauer in Japan?

You can purchase BS03-74VH/DHE08LA4-TF-G-K2A005 by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the BS03-74VH/DHE08LA4-TF-G-K2A005?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Bauer in Japan?

While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.

How can I access BS03-74VH/DHE08LA4-TF-G-K2A005 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for BS03-74VH/DHE08LA4-TF-G-K2A005 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for BS03-74VH/DHE08LA4-TF-G-K2A005?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
