Prices BS03-34V/DHE08MA4-TF-K2A003 Bauer Japan

BRAND	Bauer
Product	BS03-34V/DHE08MA4-TF-K2A003
Description	Motor
Internal code	YUS3375270
Weight	14
Technical specification	Product no.: 188Y6675 Etak2.0 worm gear motor Tipo: BS03-34V/DHE08MA4-TF-K2A003 Engine power (kW): 0.37-S9 Installation: V2 AW speed (r/min): 106 Terminal box location: II/C2 Torque (Nm): 26.0 Dimension Image: BS03 Operating Factor fB: 2,1 Catalogue: DG 07 Corrosion protection: standard net weight p.st.: approx. 14 kg Paint: RAL 9018 Ambient temperature °C: -20 - +40 Additional/special versions: total coating thickness of 80 μm Gearbox design: Type: BS03 1-stage worm gear reducer Version code number 34V: with standard flange on the front side (d: 120 mm) hollow shaft with keyway (d: 20 mm) Overall reduction ratio i: 13.50 Additional/special versions: Lubricant grade: PGLP 220 Engine design: Type: three-phase squirrel cage motor DHE08MA4-TF-K2A003 Voltage (V): 350 Rated Speed (r/min): 1420 Stator connection: Y IP protection class according to EN 60529: IP 65 Frequency (Hz): 50 IC cooling mode according to EN 60034-6: IC 411 Rated current (A): 1.20 Version according to DIN VDE 0530-1/EN 60034-1 Power Factor (Cos Phi) :0.70 Terminal Box Size: ETak20 Heat class: F Additional/special versions: With built-in thermistors for shutdown according to additional connection diagram Z010.1040-14. Operation via fitted frequency inverters: in the frequency range Hz: 5 15 50 100 Power kW: 0.026 0.115 0.37 0.37 Synchronous speed of AW n2:11 33 111 220 Load torque (Nm): 13.6 21 25.5 10.7 Load current approx. A: 0.99 1.12 1.2 0.95 Technical data of the frequency converter with accessories: type: ETak2.0 Model: K2A003 : with memory module Power: 0.37 kW - BG 1 Power plug: M12 Communication unit: with PROFIBUS Construction: motor mounted Inverter data: Mains voltage: 380V... 500V Mains frequency: 50/60 Hz Output current: 1.3/1.1 A (at mains voltage 400/480 V) Degree of protection: IP65 Precautions against: motor overtemperature : i2t monitoring : 200% rated motor torque for 3 s : 150% rated motor torque for 60 s : integrated PID controller Approvals: CE, UR, CuR, RoHS Parameter set: default Efficiency: The motor and frequency converter combinations (PDS) are classified according to IEC 61800-9-2 and meet system efficiency class IES 2.

You can find the current prices belongs to Bauer - BS03-34V/DHE08MA4-TF-K2A003 coded Motor product. You can ask all the codes and references except BS03-34V/DHE08MA4-TF-K2A003 too. It distinguishes with price and quality among the similar products. It produced result of tests of laborotory for years. BS03-34V/DHE08MA4-TF-K2A003 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy BS03-34V/DHE08MA4-TF-K2A003 by Bauer in Japan?

You can purchase BS03-34V/DHE08MA4-TF-K2A003 by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the BS03-34V/DHE08MA4-TF-K2A003?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Bauer in Japan?

While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.

How can I access BS03-34V/DHE08MA4-TF-K2A003 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for BS03-34V/DHE08MA4-TF-K2A003 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for BS03-34V/DHE08MA4-TF-K2A003?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
