| BRAND | Bauer |
| Product | BS03-34V/D05LA4/SP |
| Description | Worm gear motor |
| Internal code | YUS4205306 |
| Weight | 5.4 |
| Custom code | 85015100 |
| Technical specification | Material Code: 30584618 BCAS item number 189B1268 Item number: 189B1268 Engine power: 0.25 kW Rotation speed of the AW: 27.0 r/min Torque: 51 Nm Operating factor fB: 1.1 Installation: H1-V2 Terminal Box Location: II/A Corrosion protection: Standard Paint: RAL 7031 Dimensions: BS03 Catalog: DG 07 Net weight per piece: approx. 5.4 kg Auxor/special versions: Nameplate additionally stamped with: Installation H1 - V2 Customer ID No. 706198/9 Suitable for ambient temperatures from -10 to 50°C. Density label opposite terminal box on stand housing The lubricant quantity is adapted for use in different installation positions! Operation with an adjusted = increased amount of lubricant without gearbox ventilation leads to higher gearbox internal pressure and reduces the service life of the shaft seal, which can be used in the classification of the service intervals must be taken into account. Design of the gearbox: Type: BS03 1-stage worm gear Design code 34V with standard flange on front side (d: 120 mm) Hollow Shaft with Keyway (d: 20 mm) Total reduction i: 50.00 Auxor/special versions: Lubricant grade: PGLP 220 Working shaft ground on CNC machine twist free Design of the engine: Type: Three-phase squirrel-cage motor D05LA4 Rated speed: 1350 r/min Voltage: 230/400 V Stand circuit: D/Y Frequency: 50 Hz Rated current: 1.52/0.88 A Power factor cos phi: 0.69 Thermal class: F IP protection class n. EN 60034: IP 54 IC cooling mode according to EN 60034-6: IC 411 Terminal Box: KAG2 according to DIN VDE 0530-1/EN 60034-1 |
Where can I buy BS03-34V/D05LA4/SP by Bauer in Japan?
You can purchase BS03-34V/D05LA4/SP by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the BS03-34V/D05LA4/SP?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Bauer in Japan?
While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.
How can I access BS03-34V/D05LA4/SP catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for BS03-34V/D05LA4/SP on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for BS03-34V/D05LA4/SP?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
