Prices BS03-34VH/DPE08XA4-TF-G Bauer Japan

BRAND	Bauer
Product	BS03-34VH/DPE08XA4-TF-G
Description	gear motor
Internal code	YUS4742108
Weight	12.9
Custom code	85015100
Technical specification	screw gear motor BS03-34VH/DPE08XA4-TF-G Motor power: 0.55 kW AW speed: 143 r/min Torque: 30.5 Nm Operating factor fB: 1.7 Lineup: H3 Terminal box location: II/C Corrosion protection: standard Painting: RAL 7031 Dimension diagram: BS03 Catalogue: B 2010 Net weight per piece: approx. 13 kg Gearbox design: Type: BS03 1-stage screw gearbox Design code 34VH with standard flange on front side + back (d: 120 mm) Hollow shaft with spring groove (d: 20 mm) Total reduction i: 10.00 Additional/special versions: Lubricant grade: PGLP 220 Engine design: Type: DPE08XA4-TF-G three-phase cage rotor motor Design speed: 1430 r/min Voltage: 400 V Stator circuit: Y Frequency: 50 Hz Rated current: 1.40 A cos phi power factor: 0.70 Efficiency: IE3 - 81.2% (according to EN 60034-2-1) Warmth class: F IP protection class according to EN 60529: IP 65 IC cooling type according to EN 60034-6: IC 411 Terminal box: KAG2 Design in accordance with DIN VDE 0530-1/EN 60034-1 Additional/special versions: With built-in thermistors for shutdown according to additional connection diagram ZK010.1040-14 With attached incremental encoder Type: EIL580 Pulse frequency (imp/umdr): 256 DC supply voltage: 8.. 30 V HTL Output signals: A; B; N+Inv Power consumption: max. 70 mA IP protection class according to EN 60 529: IP 65 Express speedometer connection via plug

Bauer - BS03-34VH/DPE08XA4-TF-G referenced gear motor product produced by high technology.
BS03-34VH/DPE08XA4-TF-G became irreplaceable of foundations. Our company supply BS03-34VH/DPE08XA4-TF-G referenced product fastest and securest on your request. It produced result of tests of laborotory for years. Make an offer to us for BS03-34VH/DPE08XA4-TF-G please contact us.

Where can I buy BS03-34VH/DPE08XA4-TF-G by Bauer in Japan?

You can purchase BS03-34VH/DPE08XA4-TF-G by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the BS03-34VH/DPE08XA4-TF-G?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Bauer in Japan?

While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.

How can I access BS03-34VH/DPE08XA4-TF-G catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for BS03-34VH/DPE08XA4-TF-G on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for BS03-34VH/DPE08XA4-TF-G?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
