| BRAND | Bauer |
| Product | BK60-54VO/D13LA82-D-S/ESX040A7HA/SP |
| Description | Bevel gear motor |
| Internal code | YUS4822152 |
| Weight | 326.4 |
| Custom code | 85015220 |
| Technical specification | Material number 30596768 Article number: 189C1876 Bevel gear motor with single-disc spring brake BK60-54VO/D13LA82-D-S/ESX040A7HA/SP Engine power: 1.1/4.5 kW AW speed: 5.8/23.5 r/min Torque: 1810/1820 Nm Operating factor fB: 1.25/1.25 Lineup: H4 Terminal box location: II/A Corrosion protection: standard Paint: RAL 7031 Dimension picture: BK60-BK60Z; N-SD Catalogue: DG 07 Net weight per piece: approx. 163 kg Additional/special versions: Suitable for ambient temperatures from -40 to 40°C. Transmission design: Type: BK60 3-stage bevel gear Design code 54VO with torque support on the front side at the top Hollow shaft with keyway (d: 60 mm) Total ratio i: 122.5 Additional/special versions: 2 rubber buffers are supplied loose. with mounting aid -hold-free- as an additional pack Sealing cap on transmission side H Lubricant type: PAO68 With Heinrich's ventilation. Engine design: Type: Three-phase squirrel cage motor with pole changeover D13LA82-D-S Rated speed: 710/2840 r/min Voltage: 400 V Stator circuit: Y/Y Frequency: 50 Hz Rated current: 4.0/10.1 A Power factor cos phi: 0.59/0.90 Heat class: F IP protection class according to EN 60529: IP 65 IC cooling type according to EN 60034-6: IC 411 Terminal box: TB322 Design according to DIN VDE 0530-1/EN 60034-1 Additional/special versions: Pole-switchable with two separate stator windings With protective cover. Fan blades made of aluminum. With Klüber Petamo GHY 133 engine bearing grease Brake design: working brake under the fan shroud Type: ESX 040 A 7 HA single disc spring brake Setting value: 22.0 Nm IP protection class according to EN 60 529: IP 65 Coil voltage: 180 V Coil current: 0.33 A Additional dimension diagram: N-BR Cable version, connection ends of the magnetic coil routed to the rectifier in the motor terminal box. Additional/special versions: With lockable hand ventilation. With standard rectifier built into the motor terminal box Type: SG 3.575 B AC supply voltage: 380.. 420 V (50/60 Hz) Connected current: 0.23 A DC output: 180 V |
Where can I buy BK60-54VO/D13LA82-D-S/ESX040A7HA/SP by Bauer in Japan?
You can purchase BK60-54VO/D13LA82-D-S/ESX040A7HA/SP by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the BK60-54VO/D13LA82-D-S/ESX040A7HA/SP?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Bauer in Japan?
While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.
How can I access BK60-54VO/D13LA82-D-S/ESX040A7HA/SP catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for BK60-54VO/D13LA82-D-S/ESX040A7HA/SP on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for BK60-54VO/D13LA82-D-S/ESX040A7HA/SP?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
