| BRAND | Bauer |
| Product | BG10-27/D08MA4-TOF-S/ESX010A9HA |
| Description | motor |
| Internal code | YUS4707080 |
| Weight | 21.8 |
| Custom code | 85015100 |
| Technical specification | Spur gear motor with single-disc spring brake BG10-27/D08MA4-TOF-S/ESX010A9HA Motor power: 0.75-S3/S 6-60% kW Speed of the AW: 151 r/min Torque: 47.0 Nm Operating factor fB: 2.1 Line-up: B5 Terminal box location: I/A Corrosion protection: standard Painting: RAL 7031 Dimensional image: BG10-BG10Z Catalogue: DG 07 Net weight per piece: approx. 22 kg Transmission design: Type: BG10 2-stage helical gearbox Version code number 27 with small flange on the front side (d: 120 mm) Pivot shaft on transmission side V for flange version (d: 20 mm) Total reduction i: 9.33 Motor design: Type: Three-phase squirrel cage motor D08MA4-TOF-S Rated speed: 1400 r/min Voltage: 400 V Stator circuit: Y frequency: 50 Hz Rated current: 2.0 A Power factor cos phi: 0.81 Warmth class: F IP protection class according to EN 60529: IP 65 IC cooling type according to EN 60034-6: IC 411 Terminal box: KAG2 Design in accordance with DIN VDE 0530-1/EN 60034-1 Additional/special versions: With built-in thermostats “opener” for shut-off in accordance with insulation class F according to additional connection diagram ZK010.1030-13. Type: ESX 010 A 9 HA single-disc spring brake Setting value: 10.0 Nm IP protection class according to EN 60 529: IP 65 coil voltage: 180 V Coil current: 0.17 A Additional measurement image: N-BR Cable design, solenoid coil connectors connected to rectifiers in the motor terminal box. Additional/special versions: With lockable hand ventilation. With standard rectifier built into the motor terminal box Type: SG 3.575 B AC supply voltage: 380.. 420 V (50/60 Hz) Connection current: 0.12 A DC output: 180 V Please note: motor The motor is designed for S3/S 6-60% operating mode. Please follow the instructions on motor protection in the main list! The motor is connected via CAGE-CLAMP (cage tension spring technology)! CAGE CLAMP is a registered trademark of WAGO |
Where can I buy BG10-27/D08MA4-TOF-S/ESX010A9HA by Bauer in Japan?
You can purchase BG10-27/D08MA4-TOF-S/ESX010A9HA by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the BG10-27/D08MA4-TOF-S/ESX010A9HA?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Bauer in Japan?
While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.
How can I access BG10-27/D08MA4-TOF-S/ESX010A9HA catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for BG10-27/D08MA4-TOF-S/ESX010A9HA on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for BG10-27/D08MA4-TOF-S/ESX010A9HA?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
