Prices BG06-31/D06LA4-TOF-K/E003B4 Bauer Japan

BRAND	Bauer
Product	BG06-31/D06LA4-TOF-K/E003B4
Description	Motor
Internal code	YUS3700889
Weight	11
Technical specification	Artikel-Nr.: 188U8692 Helical-geared motor with Single-disc spring setting brake Type : BG06-31/D06LA4-TOF-K/E003B4 Motor power (kW) : 0,25 Mounting : B5 Output shaft speed (rpm) : 110 Terminal box position : I / A Dimensional drawing : BG06 Corrosion protection : Standard Catalogue : DG 07 Painting : RAL 7035 net weight per unit : ca. 11 kg ambient temperature °C : -20 - +40 Add.-/Special design: Output plate additional stamped with: Customer ID no. 394.512/8 Suitable for operation on static converter in the frequency range : 30 - 50 - 87 - 100 Hz Voltage : 150 - 230 - 400 - 400 V D Output : 0,164 - 0,25 - 0,45 - 0,52 kW synchron speed : 73 - 121 - 210 - 240 rpm Constant torque : 21,5 Nm Load current approximately : 1,68 A Gear design: Type : BG06 2 -staged Helical gear Design code 31 : with standard flange on side front (d: 120 mm) : solid output shaft on gear side front (d: 17 mm) Total gear reduction i : 12,30 Oil-type/-volume (l) : CLP 220 / 0,08 Design of the motor: Type : Three-phase squirrel cage motor D06LA4-TOF-K Voltage (V) : 230 Rated speed (rpm) : 1350 Connection : D IP prot. type per EN 60529 : IP 65 Frequency (Hz) : 50 IC cool. type EN 60034-6 : IC 411 Rated current (A) : 1,54 Design acc. to DIN VDE 0530-1/EN 60034-1 Power factor (cos phi) : 0,69 Terminal box size : KAG2 Temperature class : F Add.-/Special design: with built-in thermostats "opening" for release correspond to Insulation Class F per supplemental connection diagram ZK010.1030-13. Design of the brake: Brake below the fan cowl Type : Single-disc spring setting brake E 003 B 4 Braking torque : 1,50 Nm IP prot. type per EN 60 529 : IP 65 supplemental dim. drawing : N-BR Coil voltage : 24 V Coil current : 0.74 A Connection voltage DC : 24 V Add.-/Special design: Standard varistor

Bauer - BG06-31/D06LA4-TOF-K/E003B4 referenced Motor product produced by high technology.
BG06-31/D06LA4-TOF-K/E003B4 became irreplaceable of foundations. BG06-31/D06LA4-TOF-K/E003B4 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. BG06-31/D06LA4-TOF-K/E003B4 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy BG06-31/D06LA4-TOF-K/E003B4 by Bauer in Japan?

You can purchase BG06-31/D06LA4-TOF-K/E003B4 by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the BG06-31/D06LA4-TOF-K/E003B4?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Bauer in Japan?

While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.

How can I access BG06-31/D06LA4-TOF-K/E003B4 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for BG06-31/D06LA4-TOF-K/E003B4 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for BG06-31/D06LA4-TOF-K/E003B4?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
