| BRAND | Bauer |
| Product | BF20-24/D09XA42-TOF-S/ESX010A9HA |
| Description | motor |
| Internal code | YUS4707083 |
| Weight | 48.5 |
| Custom code | 85015220 |
| Technical specification | Flat gear motor with single-disc spring brake BF20-24/D09XA42-TOF-S/ESX010A9HA Motor power: 0.63/1.25 kW Speed of the AW: 46.5/93 r/min Torque: 129/128 Nm Operating factor fB: 3.3/3.3 Line-up: H1 Terminal box location: I/A Corrosion protection: standard Painting: RAL 7031 Dimensional image: BF20-BF20Z Catalogue: DG 07 Net weight per piece: approx. 49 kg Additional/special versions: Total coating thickness 40 μm Transmission design: Type: BF20 2-stage flat gearbox Version code number 24 with small flange on the front side (d: 200 mm) hollow shaft with keyhole (d: 30 mm) Total reduction i: 30.40 Additional/special versions: With mounting aid -hold-free as an accessory pack Motor design: Type: Three-phase rotor cage motor with pole shift D09XA42-TOF-S Rated speed: 1400/2800 r/min Voltage: 400 V Stator circuit: Y/Y frequency: 50 Hz Rated current: 1.85/3.0 A Power factor cos phi: 0.68/0.92 Warmth class: F IP protection class according to EN 60529: IP 65 IC cooling type according to EN 60034-6: IC 411 Terminal box: KAG2 Design in accordance with DIN VDE 0530-1/EN 60034-1 Additional/special versions: Pole-switchable with two separate stator windings With built-in thermostats “opener” for shut-off in both windings in accordance with insulation class F according to additional connection diagram ZK010.1030-19. Type: ESX 010 A 9 HA single-disc spring brake Setting value: 10.0 Nm IP protection class according to EN 60 529: IP 65 coil voltage: 180 V Coil current: 0.17 A Additional measurement image: N-BR Cable design, solenoid coil connectors connected to rectifiers in the motor terminal box. Additional/special versions: With lockable hand ventilation. With standard rectifier built into the motor terminal box Type: SG 3.575 B AC supply voltage: 380.. 420 V (50/60 Hz) Connection current: 0.12 A DC output: 180 V |
Where can I buy BF20-24/D09XA42-TOF-S/ESX010A9HA by Bauer in Japan?
You can purchase BF20-24/D09XA42-TOF-S/ESX010A9HA by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the BF20-24/D09XA42-TOF-S/ESX010A9HA?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Bauer in Japan?
While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.
How can I access BF20-24/D09XA42-TOF-S/ESX010A9HA catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for BF20-24/D09XA42-TOF-S/ESX010A9HA on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for BF20-24/D09XA42-TOF-S/ESX010A9HA?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
