| BRAND | Bauer |
| Product | 188R5192 - BF10-04/D08MA4-TF-S/ESX010A9HA |
| Description | Shaft-mounted geared motor |
| Internal code | YUS4856596 |
| Weight | 30 |
| Custom code | 85015100 |
| Technical specification | Material number 30623292 BCAS article number 188R5192 BF10-04/D08MA4-TF-S/ESX010A9HA Description Article number: 188R5192 Flat gear motor with single-disc spring brake BF10-04/D08MA4-TF-S/ESX010A9HA Motor power: 0.55 kW AW speed: 61 r/min Lineup: H4 Terminal box location: II/A Corrosion protection: standard Painting: RAL 7031 Dimension diagram: BF10-BF10Z Catalogue: DG 07 Suitable for operation on static inverters in the frequency range: 10 - 50 Hz Voltage: 115 - 400 V Y S 3-40% output: 0.113 - 0.7 kW sync. Speed: 12.5 - 64 r/min S 3-40% load torque: 84 - 112 Nm IP protection class according to EN 60529: IP 65 IC cooling type in accordance with EN 60034-6: IC 411 Terminal box: KAG2 Design in accordance with DIN VDE 0530-1/EN 60034-1 Additional/special versions: With built-in thermistors for shutdown according to additional connection diagram ZK010.1040-14. with outer ground screw Brake design: working brake under the fan cover Type: ESX 010 A 9 HA single-disc spring brake Setting value: 10.0 Nm IP protection class in accordance with EN 60 529: IP 65 coil voltage: 180 V Coil current: 0.17 A Additional size diagram: N-BR Cable design, connection ends of the magnetic coil led to the rectifier in the motor terminal box. Additional/special versions: With lockable hand ventilation. With standard rectifier installed in the motor terminal box Type: SG 3.575 B AC supply voltage: 380.. 420 V (50/60 Hz) Connection current: 0.12 A DC output: 180 V Load current approx.: 2.1 A Operating factor: 2.1 Gearbox design: Type: BF10 2-stage flat transmission Version code number 04 cast with torque support Hollow shaft with spring groove (d: 25 mm) Total reduction i: 23.28 Additional/special versions: 2 rubber bumpers are supplied loose. with assembly aid -held- loose as an accessory Motor design: Type: D08MA4-TF-S three-phase cage rotor motor Rated speed: 1400 r/min Voltage: 400 V Stator circuit: Y frequency: 50 Hz Rated current: 1.60 A Cos phi power factor: 0.75 Warmth class: F Motor connection is via CAGE-CLAMP (cage spring technology)! CAGE CLAMP is a registered trademark of WAGO |
Where can I buy 188R5192 - BF10-04/D08MA4-TF-S/ESX010A9HA by Bauer in Japan?
You can purchase 188R5192 - BF10-04/D08MA4-TF-S/ESX010A9HA by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the 188R5192 - BF10-04/D08MA4-TF-S/ESX010A9HA?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Bauer in Japan?
While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.
How can I access 188R5192 - BF10-04/D08MA4-TF-S/ESX010A9HA catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 188R5192 - BF10-04/D08MA4-TF-S/ESX010A9HA on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 188R5192 - BF10-04/D08MA4-TF-S/ESX010A9HA?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
