Prices p/n: 9498, Type: SMR 6202 SG 5 Telco Japan

BRAND	Telco
Product	p/n: 9498, Type: SMR 6202 SG 5
Description	Thru Beam Photoelectric Sensor
Internal code	YUS1385833
Weight	1
Technical specification	SM 6000 SPACEMASTER™ SERIES Operation Mode Thru Beam Function Receiver Supply Voltage 10 - 32 V dc Sensing Range 2 m Output PNP Output Status N.C. Housing 9,5 x 11,5 Housing Material Plastic Connection 5 m cable Technical Data Supply Voltage 10 - 32 V dc Voltage Ripple 15 % Reverse Polarity Protected Yes Short Circuit Protected Yes Current Consumption Max. 320 mW Max. Output Load 100 mA Max. Residual Voltage 2,5 V Max. Operation Frequency 1000 Hz Response Time ton / toff 0,5 ms / 0,5 ms Hysteresis Approx. 30 % Opening Angle +/- 6° Housing Material, Front Lens Polycarbonate Housing Material, Sensor Housing Polyester Cable 3/4 x 0,14 mm² Cable Sleeve PVC Ø 4,0 mm Environmental Data Vibration 10 - 55 Hz, 0.5 mm Shock 30 g Operation Temperature -20 to +60 °C Storage Temperature -40 to +80 °C Sealing Class IP 67 Light Immunity 5˚ > 50 000 lux

Telco - p/n: 9498, Type: SMR 6202 SG 5 referenced Thru Beam Photoelectric Sensor product produced by high technology.
p/n: 9498, Type: SMR 6202 SG 5 became irreplaceable of foundations. p/n: 9498, Type: SMR 6202 SG 5 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. p/n: 9498, Type: SMR 6202 SG 5 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy p/n: 9498, Type: SMR 6202 SG 5 by Telco in Japan?

You can purchase p/n: 9498, Type: SMR 6202 SG 5 by Telco from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the p/n: 9498, Type: SMR 6202 SG 5?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Telco in Japan?

While we are not the official distributor or seller of Telco in Japan, we source our products from reliable channels and offer you original Telco equipment at competitive prices.

How can I access p/n: 9498, Type: SMR 6202 SG 5 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for p/n: 9498, Type: SMR 6202 SG 5 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for p/n: 9498, Type: SMR 6202 SG 5?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
