Prices p/n: 7743, Type: SMR 6202 AP 5 Telco Japan

BRAND	Telco
Product	p/n: 7743, Type: SMR 6202 AP 5
Description	Thru Beam Photoelectric Sensor
Internal code	YUS1385831
Weight	1
Technical specification	Operation Mode Thru Beam Function Receiver Supply Voltage 10 - 32 V dc Sensing Range 2 m Output PNP Output Status N.C. Housing Ø10 Housing Material Plastic Connection 5 m cable Technical Data Supply Voltage 10 - 32 V dc Voltage Ripple 15 % Reverse Polarity Protected Yes Short Circuit Protected Yes Current Consumption Max. 320 mW Max. Output Load 100 mA Max. Residual Voltage 2,5 V Max. Operation Frequency 1000 Hz Response Time ton / toff 0,5 ms / 0,5 ms Output Indicator Yellow LED Hysteresis Approx. 30 % Opening Angle +/- 6° Housing Material, Front Lens Polycarbonate Housing Material, Sensor Housing Polycarbonate Cable 3/4 x 0,14 mm² Cable Sleeve PVC Ø 4,0 mm Environmental Data Vibration 10 - 55 Hz, 0.5 mm Shock 30 g Operation Temperature -20 to +60 °C Storage Temperature -40 to +80 °C Sealing Class IP 67 Light Immunity 5˚ > 50 000 lux

Telco - p/n: 7743, Type: SMR 6202 AP 5 referenced Thru Beam Photoelectric Sensor product produced by high technology.
You can ask all the codes and references except p/n: 7743, Type: SMR 6202 AP 5 too. Our company supply p/n: 7743, Type: SMR 6202 AP 5 referenced product fastest and securest on your request. It produced result of tests of laborotory for years. We present you the most competative price and delivery time on p/n: 7743, Type: SMR 6202 AP 5 referenced product.

Where can I buy p/n: 7743, Type: SMR 6202 AP 5 by Telco in Japan?

You can purchase p/n: 7743, Type: SMR 6202 AP 5 by Telco from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the p/n: 7743, Type: SMR 6202 AP 5?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Telco in Japan?

While we are not the official distributor or seller of Telco in Japan, we source our products from reliable channels and offer you original Telco equipment at competitive prices.

How can I access p/n: 7743, Type: SMR 6202 AP 5 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for p/n: 7743, Type: SMR 6202 AP 5 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for p/n: 7743, Type: SMR 6202 AP 5?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
