Prices p/n: 10766, Type: PABA 10 A 009 Telco Japan

BRAND	Telco
Product	p/n: 10766, Type: PABA 10 A 009
Description	Photoelectric Amplifier Bus Auto
Internal code	YUS1385568
Weight	0.132
Technical specification	Function Amplifier Supply Voltage 10 – 30 V dc / 24 V ac Number of Channels 1 Sensing Range 39 m Sensitivity Adjustment Automatic gain adjustment with adjustable excess gain Output Relay Timer On/Off Delay Housing Removable screw terminals Technical Data Supply Voltage 10 - 30 V dc or 24 V ac Voltage Tolerance +/- 10 % Current Consumption Max. 1,7 W Response Time ton / toff, Relay Short range: 27 ms / 20 ms Long range: 45 ms / 38 ms Output, Relay 250 V ac / 3 A, 120 V ac / 5 A Alarm Output, Transistor PNP - 30 V dc / 100 mA Test Input Yes Power On Indicator Green LED Output Indicator Yellow LED Alarm Indicator Red / yellow LED LR Sensor Failure Indicator Yelow LED LT Sensor Failure Indicator Red LED Master/Slave Address Indicator Green / orange LED Signal Level Indicator Green LED Sensor Monitor LED Drive Green LED on the receiver: ‘Power ON’ Yellow LED on the transmitter: PAB output activated Hysteresis Approx. 35 % Operation Frequency, Relay Short range: 21 Hz Long range: 12 Hz Delay Time ton / toff 0 – 10 sec, adjustable Housing Material Polyamide Environmental Data Operation Temperature – 10 to +50 °C Storage Temperature – 40 to +80 °C Sealing Class IP 40

You can find the current prices belongs to Telco - p/n: 10766, Type: PABA 10 A 009 coded Photoelectric Amplifier Bus Auto product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. All of the listed products are with guaranteed origin and high quality. Our company can make an offer even if we do not distributor of Japan. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy p/n: 10766, Type: PABA 10 A 009 by Telco in Japan?

You can purchase p/n: 10766, Type: PABA 10 A 009 by Telco from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the p/n: 10766, Type: PABA 10 A 009?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Telco in Japan?

While we are not the official distributor or seller of Telco in Japan, we source our products from reliable channels and offer you original Telco equipment at competitive prices.

How can I access p/n: 10766, Type: PABA 10 A 009 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for p/n: 10766, Type: PABA 10 A 009 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for p/n: 10766, Type: PABA 10 A 009?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
