Prices ASF3-50RD-171197R Steimel Japan

BRAND	Steimel
Product	ASF3-50RD-171197R
Description	GEARPUMP
Internal code	YUS3331404
Weight	45
Custom code	84136039
Technical specification	A-SF3/50RD-VLFM, pumping unit, 2-18 bar 4.0 kW, 1500, 230/400 V, 50 Hz, IP55, F, B5, IE3, steel base Gear pump unit: SF 3/50 RD - VLFM Artikel-Nr.: ASF3-50RD-171197R Dimensionsblatt: DPA053D-112LFM-R31 Spare parts list: DET053050RD--165R Suction and Pressure Connection: SAE 1 1/2 Housing parts: EN-GJL-250 (GG-25) Pinion shafts, noise-resistant: 16MnCrS5, egh., angular distortion Storage: multi-layer Shaft sealing: radial shaft sealing ring Elastomers: FKM Delivery medium: lubricating oil Viscosity: 50 - 5000 cSt Temperature: 10 - 60°C Flow rate: approx. 70.8/84.9 l/min. Pressure: 5 bar Speed: 1450/1740 rpm Pressure relief valve Opening pressure: 8 bar Adjustment range: 2 - 18 bar Direction of Rotation: Right Test run: yes, with HLPD 46 Coupling: BKUA055-1928-301 Pump Carrier with Foot: BLF053250128--03, St - welded, primed Three-phase engine: LDM112-04-074 (Birkenbeul) Engine data: Power 1/ 2:4.0 /4.6 kW Speed 1/ 2:1500 /1800 rpm Voltage/frequency 1:230 /400 volts at 50 Hz Voltage/frequency 2:265 /460 volts at 60 Hz Efficiency class: IE3 With additional sign (without IE3) for Voltage/frequency: 220-240/380-420 V at 50/60 Hz 250-280/440-480 V at 60 Hz reduce. Output: 3.68/4.23 kW at KT 50°C Protection class: IP 55 Insulation class: F to B Special Feature: Tropically Isolated for 100% Relative humidity at 50°C Design: B 5 Aggregate paint: primed Type plate: ETY924-D-E--PE02

Steimel - ASF3-50RD-171197R referenced GEARPUMP product produced by high technology.
ASF3-50RD-171197R is the result of a far more developed technology compared to similar regular products. ASF3-50RD-171197R referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Our company can make an offer even if we do not distributor of Japan. We present you the most competative price and delivery time on ASF3-50RD-171197R referenced product.

Where can I buy ASF3-50RD-171197R by Steimel in Japan?

You can purchase ASF3-50RD-171197R by Steimel from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the ASF3-50RD-171197R?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Steimel in Japan?

While we are not the official distributor or seller of Steimel in Japan, we source our products from reliable channels and offer you original Steimel equipment at competitive prices.

How can I access ASF3-50RD-171197R catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for ASF3-50RD-171197R on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for ASF3-50RD-171197R?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
