Prices ASF2-20RD-241708R Steimel Japan

BRAND

Steimel

Product

ASF2-20RD-241708R

Internal code

YUS5153724

Weight

Technical specification

A-SF2/20RD-VLFM, pump unit according to ATEX

1.5kW, 1500, 400/690V, IE3, 50Hz, IP65, PTC, F, VIK

gear pump unit	:	SF 2/20 RD - VLFM
in accordance with Directive 2014/34/EU (ATEX)
Item no. Dimension sheet Spare parts list Suction and pressure connection housing parts Sprocket shafts, noise-opti. warehousing	: : : : : :	ASF2-20RD-241708R DPA052D-241686R DET052020-182207R G 1/SAE 1 EN-GJL-250 (GG-25) 16MnCrS5, egh., oblique	:
Multi-layer MD
shaft sealing	:	radial shaft seal
elastomers Temperature monitoring	: :	FKM PT100 resistance thermometer, wired in the terminal box, BTW004 Type examination certificate: ibexu14ATEX1281 U
Limit value switch pumping medium viscosity temperature flow rate	:	On site, limit value max. 90°C
:	lube
:	50-5000 cSt
: :	10 - max. 80°C approx. 28.5 l/min

printing	:	5 bar
rpm	:	1450 rpm
pressure relief valve opening pressure adjustment range	: :	8 bar 2-20 bar
direction of rotation	:	right
coupling pump carrier with foot three-phase motor power rpm Voltage/ frequency Protection class insulation class Ignition protection type motor protection Ambient temperature construction version Aggregate paint ATEX type plate ATEX label pumping unit	:	BKUA040-1424-303 (ATEX)
: : : : : : : : : : : : : :	BLF052200110LA21 LDX090-04-064 (HEW) 1.5 kW 1500 rpm 400/690 volts/50 Hz IP 65 F to B II 2G Exdb eb IIC T4Gb 3 cold conductors -20°C to +40ºC B5 VIK primed RAL 6011 (HDO058) ETY924FLEND-PE03
:	II 2G Ex h IIB T4Gb X

Please note the regulations
in accordance with Directive 2014/34/EU (ATEX)
regarding the use of our pumps in
potentially explosive areas.
Prerequisite for operation in:
Zone 1 or 2
Temperature class T4
Ambient temperature -20°C to +40°C
Explosion group IIB (gas)
Temperature monitoring at the pump using
Resistance thermometer: Pt 100 included
Limit value switches and cabling: on site!
(limit value max. 90°C)
Before starting up the pump, the temperature monitoring must
Be functionally connected on site!

Steimel - ASF2-20RD-241708R referenced product produced by high technology.
ASF2-20RD-241708R became irreplaceable of foundations. Our company supply ASF2-20RD-241708R referenced product fastest and securest on your request. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. ASF2-20RD-241708R referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy ASF2-20RD-241708R by Steimel in Japan?

You can purchase ASF2-20RD-241708R by Steimel from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the ASF2-20RD-241708R?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Steimel in Japan?

While we are not the official distributor or seller of Steimel in Japan, we source our products from reliable channels and offer you original Steimel equipment at competitive prices.

How can I access ASF2-20RD-241708R catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for ASF2-20RD-241708R on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for ASF2-20RD-241708R?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
