| BRAND | Autosen |
| Product | AF003 |
| Description | Electronic level sensor |
| Internal code | YUS4473364 |
| Weight | 0.3 |
| Custom code | 90261029 |
| Technical specification | G3/4M 100 ... 1600 mm Range of applicationWater-based cooling lubricants, oils, water / media similar to water Cannot be used for:Greases; granulates; bulk materials; acids; alkaline solutions; heavily foaming media Dielectric constant of medium> 2; (for media with DK 2...20 (oils), a coaxial tube is required for operation) Sensor typeGuided microwave Outputs / inputs Switching outputNormally open / Normally closed programmable Analogue output4 ... 20 mA 0 ... 10 V Programmable Scalable Comment on analogue outputWhen used with an analog output use exclusively sensor cables without LED IO-LinkYes Electrical data Operating voltage18 ... 30 V DC Voltage typeDirect voltage (DC) Electrical designPNP Current carrying capacity max.200 mA Voltage drop max.2.5 V Current consumption max.80 mA Protection classIII Short-circuit protectionYes Overload-proofYes Reverse polarity protectionYes Ready delay3 s Mechanical data Active range AL-40 (L-60); (with setting for oil and oil-based media) Materials in contact with the mediumV4A (1.4404) V4A (1.4435) Seal: Tesnit FKM PTFE Material of housingPEI PBT V2A (1.4305) FKM PTFE TPE / V PC Electrical connectionM12 4-pin Contacts gold-plated Process connectionExternal thread G 3/4 Probe length L100 ... 1600 mm Comment(See accessories) Accuracy Resolution± 10 mm Switching point accuracy± 20 mm Ambient conditions Ambient temperature min.0 °C Ambient temperature max.60 °C Maximum container pressure-1...16 bar Medium temperature0 ... 80 °C; (90 °C < 1 h) °C Protection ratingIP67 Additional information MTTF174 years Function display4 x LED Display Yellow Green Programming keys 4-digit display Accessories included with deliverySeal EMC testIEC 60947-1 Shock resistance testDIN IEC 68-2-27 Vibration resistance testDIN IEC 68-2-6 ApprovalCE cULus |
Where can I buy AF003 by Autosen in Japan?
You can purchase AF003 by Autosen from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the AF003?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Autosen in Japan?
While we are not the official distributor or seller of Autosen in Japan, we source our products from reliable channels and offer you original Autosen equipment at competitive prices.
How can I access AF003 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for AF003 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for AF003?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
