Prices 273898 8570/11-506-S-01-0-00-XXX Stahl Japan

BRAND	Stahl
Product	273898 8570/11-506-S-01-0-00-XXX
Description	Wall socket
Internal code	YUS4962878
Weight	2.4
Technical specification	16 A explosion-proof Rated operating voltage: 200/346 ... 240/415 V AC Frequency range: 50/60 Hz Detailed number of poles: 3 P + N + PE Identifying color: red Coding (time setting): 6 Housing material: Polyamide, glass fiber reinforced Silicone-free: No Area of application (zones): 1,2,21,22 Scope: European Union (ATEX) Gas explosion protection: II 2 G Ex db eb IIC T6 # T5 Gb Dust explosion protection: II 2 D Ex tb IIIC T73 °C Db Ambient temperature min.: -50 °C Ambient temperature max.: +35 °C Rated operating current: 16 A Ambient temperature min.2: -50 °C Ambient temperature max.2: +65 °C Rated operating current2: 6 A Ambient temperature min. F: -58 °F Ambient temperature max. F: +95 °F Ambient temperature min. °F 2: -58 °F Ambient temperature max. °F 2: +149 °F Protection class IP (IEC 60529): IP66 Protection class IP (IEC 60079): IP64 Impact resistance (IEC 60079): 7.00 J Impact resistance (IEC 62262): IK10 Introduction 1: M25 x 1.5 Introduction 1 Type: Polyamide cable gland Introduction 1 Type: 8161/7-M25-1707-LT Introduction 1 clamp area. : 7 - 17mm Introduction 2: M25 x 1.5 Introduction 2 Type: Polyamide sealing plug Introduction 2 Type: 8290/3-M25

Stahl - 273898 8570/11-506-S-01-0-00-XXX referenced Wall socket product produced by high technology.
273898 8570/11-506-S-01-0-00-XXX became irreplaceable of foundations. Our company supply 273898 8570/11-506-S-01-0-00-XXX referenced product fastest and securest on your request. You can find the most competitive prices about endustriel accessories in our company. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy 273898 8570/11-506-S-01-0-00-XXX by Stahl in Japan?

You can purchase 273898 8570/11-506-S-01-0-00-XXX by Stahl from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the 273898 8570/11-506-S-01-0-00-XXX?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Stahl in Japan?

While we are not the official distributor or seller of Stahl in Japan, we source our products from reliable channels and offer you original Stahl equipment at competitive prices.

How can I access 273898 8570/11-506-S-01-0-00-XXX catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 273898 8570/11-506-S-01-0-00-XXX on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 273898 8570/11-506-S-01-0-00-XXX?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
