Prices 1L532 DAYTON Japan

BRAND	DAYTON
Product	1L532
Description	AC Gearmotor
Internal code	YUS5041750
Weight	3.62874
Technical specification	Parallel, Single Output Shaft, PSC, Open, 1.2 RPM, 100 in-lb Max Torque, CW/CCW Nameplate Speed 1.2 RPM Maximum Torque 100 in-lb Input Horsepower 0.013 hp Overhung Load Capacity 90 ft-lb Phase Single Operating Voltage 230V AC Full Load Current 0.2 A Rotation CW/CCW Shaft Orientation Parallel Number of Output Shafts 1 Motor Type Permanent Split Capacitor Motor Enclosure Open Air-Over Mounting Orientation Any Angle Inverter Rated No Thermal Protection None Maximum Ambient Temperature 104 °F Capacitor Required Yes Includes Capacitor Capacitor Included Gear Ratio 1369:1 Gear Type Helical (1st Stage); Spur Gear Material Steel or Heat Treated Powdered Metal Brake Type None Output Shaft Diameter 1/2 in Output Shaft Length 1 in Bearing Type Ball on Motor; Heavy Duty Needle on Case Seal Type Spring Loaded Lip Type on Input and Output Shaft Lubrication Permanent Heavy Duty Gear Oil Mount Type Any Position Length Less Shaft 7.88 in Overall Width 3.63 in Overall Height 5.38 in Application Washdown Standards C-UL Recognized; CE Certified; UL Recognized Frequency 50 Hz; 60 Hz UNSPSC 26101602 Country of Origin USA (subject to change)

You can find the current prices belongs to DAYTON - 1L532 coded AC Gearmotor product. You can ask all the codes and references except 1L532 too. It distinguishes with price and quality among the similar products. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Make an offer to us for 1L532 please contact us.

Where can I buy 1L532 by DAYTON in Japan?

You can purchase 1L532 by DAYTON from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.

What is the price of the 1L532?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of DAYTON in Japan?

While we are not the official distributor or seller of DAYTON in Japan, we source our products from reliable channels and offer you original DAYTON equipment at competitive prices.

How can I access 1L532 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 1L532 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 1L532?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
