| BRAND | Bauer |
| Product | 189F8068 / BG20-47/DXS08XB4-TX-ST-ZW-S-BR/SP |
| Description | Spur gear motor |
| Internal code | YUS4737880 |
| Weight | 29 |
| Custom code | 85015100 |
| Technical specification | with single-disc spring-pressure brake Ex marking: II3DExtCIIICt160°cdc Motor power: 0.75 kW Speed of the AW: 92 r/min Line-up: B5 Terminal box location: I/B Corrosion protection: standard Painting: RAL 7031 Dimensional image: BG20-BG20Z Catalogue: DG 07 Suitable for operation on a static converter in the frequency range: 8.7 - 50 Hz Voltage: 59 - 230 V Y Power: 0.098 - 0.53 kW Synchronous Speed: 16.5 - 96 r/min const. Load moment: 56 Nm Load current approx.: 2.9 A Operating factor: 3.2 Transmission design: Type: BG20 2-stage helical gearbox Version: II 2 G Ex h IIC T3 Gb/II 2 D Ex h IIIC T160°C Db according to: EN80079-36, -37 Version code number 47 with large flange on the front side (d: 200 mm) Pivot shaft on transmission side V for flange version Total reduction i: 15.58 Additional/special versions: Special work wave in accordance with ZN.BG20-31-A3-K075. (d x l): 25mm x 125mm), without key groove, collar brought forward 12 mm, material no. 30419061 Motor design: Special design explosion-proof three-phase squirrel-cage motor for use in category 3D, zone 22 Tipo: DXS08XB4-TX-ST-ZW-S Ex marking: II3DExtCIIICt160°cdc Rated speed: 1425 r/min Voltage: 230 V Stator circuit: Y frequency: 50 Hz Rated current: 3.25 A Relative starting current IA/IN: 5.3 Power factor cos phi: 0.71 Efficiency: IE3 - 82.5% (according to EN 60034-2-1) Warmth class: F IP protection class according to EN 60529: IP 65 IC cooling type according to EN 60034-6: IC 411 Terminal Box Size: TBS112 Version according to EN 60034 and EN 60079 Additional/special versions: Harting connector HAN 10 ES according to the dimensions diagram TBS11.-06-A3 and connection diagram HS11210000/01: Mounting housing 09 300 100 301 - 2 brackets Pin insert 09 330 102 616 sleeve housing - socket insert - Coverage 09 300 105 407 With built-in thermistors for shut-off according to additional connection diagram Z010.1040-14. Fan blade made of aluminum. with outer ground screw 2nd shaft end according to ZN.D08-31L-EG-A4-W-K001. d x l: 14g7 x 35 mm, shaft collar flush with Fan cover, without keyhole, material no.: 30539095 Brake design: holding brake under the fan cover Type: FDW 10 single disc spring brake Setting value: 10.0 Nm IP protection class according to EN 60 529: IP 65 Coil voltage: 103 V Coil current: 0.31 A ATEX certification: CE Ex II 3D Ex tc IIIC T125°C DC Additional measurement image: N-BR Cable design, solenoid coil connectors connected to rectifiers in the motor terminal box. Additional/special versions: Special brake in accordance with ZN.30527350. With non-lockable hand ventilation. Hand fan lever in position II With built-in thermistor for shut-off according to additional connection diagram ZK0... Brake was selected based on application-specific data. Drive is only for Scope allowed up to the limits of application-specific data. Load moment on rotor: 5 Nm Ext.traegh.mom. on LW: 0.02 kgm^2 Friction/Braking: 500 J Switching frequency/hour: 5 c/h With standard rectifier built into the motor terminal box Type: SG 3.575 B AC supply voltage: 220.. 230 V (50/60 Hz) Connection current: 0.22 A DC output: 103 V |
Where can I buy 189F8068 / BG20-47/DXS08XB4-TX-ST-ZW-S-BR/SP by Bauer in Japan?
You can purchase 189F8068 / BG20-47/DXS08XB4-TX-ST-ZW-S-BR/SP by Bauer from ユサキ・オートメーション合同会社. We serve customers across Japan, offering competitive prices and reliable service.
What is the price of the 189F8068 / BG20-47/DXS08XB4-TX-ST-ZW-S-BR/SP?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Bauer in Japan?
While we are not the official distributor or seller of Bauer in Japan, we source our products from reliable channels and offer you original Bauer equipment at competitive prices.
How can I access 189F8068 / BG20-47/DXS08XB4-TX-ST-ZW-S-BR/SP catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 189F8068 / BG20-47/DXS08XB4-TX-ST-ZW-S-BR/SP on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 189F8068 / BG20-47/DXS08XB4-TX-ST-ZW-S-BR/SP?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
